AMAT Applied Materials   0150-30267雙射頻濾波器模塊

1.產 品 資 料 介 紹：

核心規(guī)格

工作原理與結構

AMAT Applied Materials   0150-30267雙射頻濾波器模塊 英文資料：

AMAT Applied Materials 0150-30267 is a dual channel bandpass RF filter module designed specifically for dual frequency RF power supply systems in semiconductor etching, PVD, and other equipment. It can simultaneously process signals from two independent frequency bands, ensuring stable power transmission and suppressing interference.

Core specifications

Project Specification Description

Two independent channels support processing two different frequency signals simultaneously

Common frequency range coverage: 2MHz-200MHz or 1GHz-3GHz, customized frequency band according to device requirements

Insertion loss ≤ 1.5dB (typical) Low loss design improves power utilization efficiency

Out of band suppression ≥ 30dB (typical) effectively suppresses stray and harmonic interference

In band fluctuation ≤ 0.8dB ensures signal flatness

Impedance 50 Ω standard RF impedance matching

Maximum input power per channel 50W-100W (depending on version) to meet high-power RF applications

Interface type SMA-F or N-F (optional) Industrial standard RF interface

Working temperature -40 ℃~+85 ℃, suitable for industrial environment

Protection level IP20 dustproof design, suitable for installation inside the electrical control box

Size approximately 120 × 80 × 40mm (excluding joints) Compact structure saves space

Working principle and structure

This module consists of two independent bandpass filter channels, each channel using a ceramic dielectric resonator+microstrip line structure, achieving high Q-value and low loss performance through multi-layer metalized ceramic substrates. The dual channels are integrated into the same shielding box, which can effectively isolate mutual interference and ensure the purity of each channel signal.

 AMAT Applied Materials   0150-30267雙射頻濾波器模塊 產品展示
