AMAT Applied Materials  3200-00004插槽機架

1.產 品 資 料 介 紹：

產品概述

AMAT 3200-00004 插槽機架（Slot Rack）是 Applied Materials 半導體設備中用于模塊化安裝和管理電路板或功能模塊的機架組件。它為 PCB 板、控制模塊、驅動模塊等提供標準化的插槽安裝位置和電氣接口，使設備內部結構整齊、可靠，同時便于模塊的快速替換和維護。

技術參數（推斷與行業常規）

• 類型：模塊化插槽機架（Slot Rack / Backplane Rack）

• 功能：支撐與固定多塊 PCB 板或模塊，提供標準化接口

• 板卡容量：可支持多塊 PCB 板（具體數量依設備設計）

• 接口形式：標準板對板或板對背板連接，支持?jǐn)?shù)字和模擬信號傳輸

• 電氣特性：低壓直流供電，兼容控制信號和電源分配

• 機械特性：耐振動、耐高溫、穩固可靠，適合潔凈室環境

• 適用設備：Applied Materials 半導體工藝設備的模塊化控制系統或子系統

應用場景

1. 模塊化電路板安裝

   • 在設備控制柜或子系統中安裝 PCB 板、監控板、驅動板等。

2. 信號與電源傳輸

   • 提供可靠的電源和信號通路，實現模塊間的數據和電力互聯。

3. 維護與替換便利

   • 支持快速拆裝和模塊替換，減少設備停機時間。

4. 系統擴展與升級

   • 通過標準化插槽，可方便地增加或更換功能模塊，滿足設備升級需求。

產品優勢

• 高可靠性：機械穩固、電氣連接穩定，適應高精度生產環境。

• 模塊化設計：便于設備擴展、升級和維護。

• 快速替換：標準化插槽設計降低維修和更換復雜度。

• 兼容性廣：適用于多種 AMAT 控制板或功能板模塊。

• 整齊有序：優化設備內部空間布局，提高散熱和管理效率。

AMAT Applied Materials 0010-70131監視器模塊 英文資料：

Product Overview

AMAT 3200-00004 Slot Rack is a rack component used in Applied Materials semiconductor equipment for modular installation and management of circuit boards or functional modules. It provides standardized slot installation positions and electrical interfaces for PCB boards, control modules, driver modules, etc., making the internal structure of the equipment neat and reliable, while facilitating quick replacement and maintenance of modules.

Technical parameters (inference and industry norms)

Type: Modular Slot Rack/Backplane Rack

Function: Support and fix multiple PCB boards or modules, provide standardized interfaces

Board capacity: Can support multiple PCB boards (specific quantity depends on equipment design)

Interface form: standard board to board or board to backplane connection, supporting digital and analog signal transmission

Electrical characteristics: Low voltage DC power supply, compatible with control signals and power distribution

Mechanical characteristics: resistant to vibration, high temperature, stable and reliable, suitable for clean room environments

Applicable equipment: Modular control systems or subsystems for Applied Materials semiconductor process equipment

Application scenarios

Modular circuit board installation

Install PCB boards, monitoring boards, driver boards, etc. in equipment control cabinets or subsystems.

Signal and power transmission

Provide reliable power and signal pathways to achieve data and power interconnection between modules.

Convenient maintenance and replacement

Support quick disassembly and module replacement, reducing equipment downtime.

System Expansion and Upgrade

Through standardized slots, it is easy to add or ｒｅｐｌａｃｅ functional modules to meet equipment upgrade needs.

Product advantages

High reliability: Mechanical stability, stable electrical connections, suitable for high-precision production environments.

Modular design: facilitates device expansion, upgrading, and maintenance.

Quick replacement: Standardized slot design reduces maintenance and replacement complexity.

Wide compatibility: suitable for various AMAT control boards or functional board modules.

Neat and orderly: Optimize the internal space layout of the equipment, improve heat dissipation and management efficiency.
