REC650 1MRK008514-AA是一款用于控制、保護和監測電網中不同類型的間隔控制裝置。
間隔控制裝置REC650 1MRK008514-AA實物拍攝視頻：
間隔控制裝置REC650 1MRK008514-AA倉庫實物圖片細節展示：
間隔控制裝置REC650 1MRK008514-AA產品詳情介紹：
設備控制功能的特點是： 一次設備的操作 選擇執行原則以提供高可靠性 防止同時操作的選擇和保留功能 操作員場所的選擇和監督 指揮監督 阻斷/解除阻斷操作 位置指示更新的塊/解塊 位置指示的替代 聯鎖功能的超越 超越同步檢查 極點不一致監督 操作計數器 | Features of the apparatus control function are: Operation of primary apparatuses? elect-Execute principle to give high reliability? Selection and reservation function to preventsimultaneous operation? Selection and supervision of operator place? Command supervision? Block/deblock of operation? Block/deblock of updating of position indications? Substitution of position indications? Overriding of interlocking functions? Overriding of synchrocheck? Pole discordance supervision? Operation counter |
以下聯鎖模塊可用： 雙母線和轉換母線的線路，ABC_Line 雙母線和轉換母線的母線耦合器，ABC_BC 雙母線變壓器間，AB_TRAFO 雙母線的母線分段斷路器，A1A2_BS 雙母線的母線段隔離開關，A1A2_DC 母線接地開關，BB_ES?雙CB間隔，DB_BUS_A、DB_LINE、DB_BUS_B 1 1/2-CB直徑，BH_LINE_A，BH_CONN，BH_LINE_B | The following interlocking modules are available: Line for double and transfer busbars, ABC_LINE Bus coupler for double and transfer busbars, ABC_BC Transformer bay for double busbars, AB_TRAFO Bus-section breaker for double busbars, A1A2_BS Bus-section disconnector for double busbars,A1A2_DC Busbar earthing switch, BB_ES? Double CB Bay, DB_BUS_A, DB_LINE, DB_BUS_B 1 1/2-CB diameter, BH_LINE_A, BH_CONN, BH_LINE_B |
