ABB REF545KB133AAAA饋線終端用于保護、控制、測量和監視中壓電網，可以和各種開關裝置，包括單母線、雙母線和雙重系統結合使用。
ABB REF545KB133AAAA饋線終端產品詳情說明：
REF545KB133AAAA 饋線終端用于中壓電網的保護、控制、測量和監視 可用于電能質量的監測、保護、電容器組的保護和控制以及電動機的保護 可以用電流電壓傳感器或者傳統的CT和PT來進行電流電壓測量 裝置的人機界面采用大液晶圖形顯示屏，且該液晶顯示屏可以和裝置分離，便于在開關柜上安裝 具有保護、控制、測量、通訊、電能質量監測和設備的狀態監視等各項功能 保護功能包括帶或不帶方向的相間過流和接地保護，零序過電壓保護、過電壓和欠電壓保護、熱過負荷保護、斷路器失靈保護以及自動重合閘等 控制功能包括斷路器、隔離開關等控制對象的就地和遠方控制和同期檢測，控制對象狀態顯示及屏柜與變電站主機間的聯鎖顯示 測量功能包括相電流、線電壓和相電壓、零序電流和零序電壓、頻率、功率因數、有功和無功功率以及電能的測量等等 設備的狀態監視包括斷路器狀態顯示、跳閘回路監視以及饋線終端的內部自檢具有同期檢查、頻率保護、電容器組的保護和控制以及電流和電壓諧波分量測量等功能RTD/模擬量測量模塊可用于溫度、電流/電壓測量和 m A 量的信號輸出 具有三個通訊接口：一個用于與PC機的就地通訊，另兩個通過變電站監控系統用于遠方通訊。 控制功能控制功能用于顯示開關設備的狀態信息，例如，斷路器和隔離開關，并用來實現開關設備的控制。此外，控制功能還提供用于控制邏輯的on/off控制功能，數據監視的各種對象控制等等。所有的控制功能和控制邏輯都可以采用軟件編制整定，裝置大液晶屏的MIMIC 配置畫面也可以用繼電器配置工具軟件編輯。一次設備的狀態就顯示在裝置液晶屏上，并實現就地控制。在MIMIC 畫面上開關設備不同狀態的顯示方式，例如分閘/合閘/不確定都是可以任意設計的。 | REF545KB133AAAA The feeder terminal is used for protection, control, measurement, and monitoring of medium voltage power grids Can be used for monitoring and protecting power quality, protecting and controlling capacitor banks, and protecting motors Current and voltage measurements can be carried out using current and voltage sensors or traditional CT and PT methods The human-machine interface of the device adopts a large LCD graphic display screen, which can be separated from the device for easy installation on the switchgear It has various functions such as protection, control, measurement, communication, power quality monitoring, and equipment status monitoring The protection functions include phase to phase overcurrent and grounding protection with or without direction, zero sequence overvoltage protection, overvoltage and undervoltage protection, thermal overload protection, circuit breaker failure protection, and automatic reclosing, etc The control functions include local and remote control and synchronous detection of control objects such as circuit breakers and isolation switches, display of control object status, and interlocking display between the screen cabinet and the substation host The measurement functions include phase current, line voltage and phase voltage, zero sequence current and zero sequence voltage, frequency, power factor, active and reactive power, and measurement of electrical energy, etc The status monitoring of equipment includes circuit breaker status display, trip circuit monitoring, and internal self check of feeder terminals, which have functions such as synchronous inspection, frequency protection, protection and control of capacitor banks, and measurement of current and voltage harmonic components |
ABB REF545KB133AAAA饋線終端產品細節圖片：
ABB REF545KB133AAAA饋線終端產品視頻：
