AB 1756-OW16I   數字繼電器模塊

1.產 品 資 料 介 紹：

中文資料：

1756-OW16I 是 Allen-Bradley ControlLogix 系列中的一個數字繼電器輸出模塊，設計用于工業自動化控制系統，提供可靠的數字繼電器輸出，適用于控制交流或直流負載。

二、主要功能

• 輸出類型：16 點繼電器輸出，適合開關控制各種負載，如電機啟動器、指示燈、閥門等。

• 繼電器規格：每點繼電器可承受高達 2A 電流，支持交流和直流負載。

• 隔離設計：繼電器輸出與控制系統電氣隔離，提高系統安全性和抗干擾能力。

• 診斷功能：支持模塊狀態和點狀態診斷，便于維護和故障檢測。

• 兼容性：完全集成于 ControlLogix 系統，可通過 Logix 5000 控制器進行配置和監控。

三、技術參數

• 輸出點數：16 點繼電器輸出

• 負載電流：每點最大 2A（具體請參考詳細技術手冊）

• 輸出類型：機械繼電器（Form C，單刀雙擲）

• 電壓范圍：可控制交流和直流電壓負載（一般為24V至250V交流，12V至30V直流）

• 隔離：繼電器觸點與模塊內部電路電氣隔離

• 電氣壽命：典型機械壽命約 10^7 次操作

• 安裝方式：ControlLogix 標準機架插入式

四、應用領域

• 工業自動化控制

• 機械設備開關控制

• 過程控制中的繼電器輸出需求

• 電氣設備遠程開關操作

• 工廠生產線設備控制

五、使用建議

• 確保負載電流和電壓在模塊規格范圍內，避免超負荷運行。

• 繼電器輸出端需正確接線，避免接線錯誤造成設備損壞。

• 利用模塊自帶的診斷功能，定期檢測繼電器狀態和模塊健康狀況。

• 配合 ControlLogix 系統編程，實現靈活的控制和故障報警。

英文資料：

1756-OW16I is a digital relay output module in the Allen Bradley ControlLogix series, designed for industrial automation control systems, providing reliable digital relay outputs suitable for controlling AC or DC loads.

2、 Main functions

Output type: 16 point relay output, suitable for switch control of various loads, such as motor starters, indicator lights, valves, etc.

Relay specifications: Each relay can withstand up to 2A current and support both AC and DC loads.

Isolation design: The relay output is electrically isolated from the control system to improve system safety and anti-interference capability.

Diagnostic function: Supports module status and point status diagnosis for easy maintenance and fault detection.

Compatibility: Fully integrated into the ControlLogix system, can be configured and monitored through the Logix 5000 controller.

3、 Technical parameters

Output points: 16 relay outputs

Load current: maximum 2A per point (please refer to the detailed technical manual for details)

Output type: Mechanical relay (Form C, single pole double throw)

Voltage range: Can control AC and DC voltage loads (generally 24V to 250V AC, 12V to 30V DC)

Isolation: Electrical isolation between relay contacts and internal circuits of the module

Electrical lifespan: The typical mechanical lifespan is approximately 10 ^ 7 operations

Installation Method: ControlLogix Standard Rack Insertion

4、 Application Fields

industrial automation control

Mechanical equipment switch control

Relay output requirements in process control

Remote switch operation of electrical equipment

Factory production line equipment control

5、 Usage suggestions

Ensure that the load current and voltage are within the module specifications to avoid overload operation.

The relay output terminal needs to be wired correctly to avoid equipment damage caused by wiring errors.

Utilize the built-in diagnostic function of the module to regularly check the status of relays and the health status of the module.

Cooperate with ControlLogix system programming to achieve flexible control and fault alarm.

2.產      品      展      示
