SANYO DENKI PQM0PA2700伺服放大器
1.產 品 資 料 介 紹：
- PQ 精準控制核心：SANYO DENKI PQM0PA2700 伺服放大器搭載先進 PQ（有功功率 / 無功功率）控制算法，可獨立調節電機輸出有功功率與無功功率，相比傳統 V/F 控制在負載突變時轉速波動降低 60%，在小型發電機測試臺架中，能精準模擬不同負載功率特性，保障測試數據的準確性。
- 中大功率適配能力：從型號標識及系列定位推測，該放大器額定適配功率約 7.5kW 級，可穩定驅動 P60B18550RBV00 等中功率伺服電機，額定輸出電流達 30A，在數控機床主軸驅動中，能提供持續轉矩輸出，滿足高速切削時的動力需求。
- 多協議通訊集成：支持 Profinet、Modbus 及 Ethernet/IP 等主流工業通訊協議，可無縫接入工廠 MES 系統，實現有功功率、無功功率等關鍵參數的實時上傳，在智能電網配套的電機驅動系統中，便于集中管控電網功率因數。
- 寬電壓自適應范圍：輸入電壓支持三相 380V±20% 波動，在電壓不穩定的重型工業車間，無需額外穩壓設備即可維持輸出穩定，配合電機低電壓?jiǎn)?dòng)能力，形成全鏈路電網適配優勢，減少因電壓?jiǎn)栴}導致的停機。
- 功率因數優化功能：通過動態調節無功功率輸出，可將系統功率因數提升至 0.95 以上，在多電機集中運行的生產線中，能降低電網無功損耗，減少電力部門的功率因數罰款，年節電成本可達設備投入的 15%。
- 高精度反饋兼容：兼容增量式、絕對式雙編碼器信號輸入，配合內置信號濾波模塊，可將位置檢測誤差控制在 ±1 個脈沖內，與 P60B18550RBV00 的編碼器冗余設計形成雙重保障，適配半導體晶圓搬運等高精度場景。
- 強化散熱與防護：采用鰭片式散熱結構與 IP20 防護等級，在 45℃環境溫度下可長期滿負荷運行，當溫度升至 55℃時自動啟動過載保護，在注塑機等靠近熱源的設備旁安裝時，無需額外散熱裝置即可穩定工作。
SANYO DENKI PQM0PA2700伺服放大器 英文資料：
PQ Precision Control Core: SANYO DENKI PQM0PA2700 servo amplifier is equipped with advanced PQ (active power/reactive power) control algorithm, which can independently adjust the motor output active power and reactive power. Compared with traditional V/F control, the speed fluctuation is reduced by 60% when the load suddenly changes. In a small generator test bench, it can accurately simulate different load power characteristics and ensure the accuracy of test data.
Medium to high power adaptation capability: Based on the model identification and series positioning, it is estimated that the amplifier has a rated adaptation power of about 7.5kW, which can stably drive medium power servo motors such as P60B18550RBV00, with a rated output current of 30A. In the spindle drive of CNC machine tools, it can provide continuous torque output to meet the power requirements during high-speed cutting.
Multi protocol communication integration: Supports mainstream industrial communication protocols such as Profinet, Modbus, and Ethernet/IP, seamlessly integrates with factory MES systems, and enables real-time upload of key parameters such as active power and reactive power. In the motor drive system supporting the smart grid, it facilitates centralized management and control of the power factor of the grid.
Wide voltage adaptive range: The input voltage supports three-phase 380V ± 20% fluctuation. In heavy industrial workshops with unstable voltage, no additional voltage stabilizing equipment is needed to maintain output stability. Combined with the low voltage starting ability of the motor, it forms a full chain power grid adaptation advantage and reduces downtime caused by voltage problems.
Power factor optimization function: By dynamically adjusting the reactive power output, the system power factor can be increased to above 0.95. In a production line with multiple motors running centrally, it can reduce reactive power losses in the power grid, reduce power factor fines for the power department, and save up to 15% of equipment investment in annual electricity costs.
High precision feedback compatibility: compatible with incremental and absolute dual encoder signal input, combined with built-in signal filtering module, the position detection error can be controlled within ± 1 pulse, forming a dual guarantee with the redundant design of P60B18550RBV00 encoder, suitable for high-precision scenarios such as semiconductor wafer handling.
Enhanced heat dissipation and protection: Adopting a finned heat dissipation structure and IP20 protection level, it can operate at full load for a long time at an ambient temperature of 45 ℃. When the temperature rises to 55 ℃, it automatically activates overload protection. When installed near equipment such as injection molding machines that are close to heat sources, it can work stably without additional heat dissipation devices.
SANYO DENKI PQM0PA2700伺服放大器 產品展示
產品視頻
