TEL Tokyo Electron AQA-K09-TYP2冷卻器組件
1.產 品 資 料 介 紹：
產品名稱：
Tokyo Electron AQA-K09-TYP2 冷卻器組件（Chiller Unit / Cooling Assembly） 是一款用于 TEL 半導體制造設備中的溫控系統關鍵部件，主要負責為工藝模塊（如反應腔、光源、電子組件等）提供精準的溫度調節和熱交換功能，以保障工藝穩定性與設備安全運行。
一、產品基本屬性
產品名稱：冷卻器組件（Chiller / Cooler Unit）
產品型號：AQA-K09-TYP2
制造商：Tokyo Electron Ltd.
模塊用途：液體或氣體溫度控制（可能為內置或外接型冷卻模塊）
二、功能與作用
| 功能類別 | 具體說明 |
|---|---|
| 溫控管理 | 控制工藝模塊、電子系統或液體回路的溫度，使之維持在預設穩定范圍 |
| 熱交換系統 | 利用冷媒或 DIW（去離子水）等循環流體帶走熱量，實現連續冷卻 |
| 集成控制接口 | 與設備主控系統（如 PLC 或溫控控制器）連接，實現溫度反饋閉環控制 |
| 工藝保護功能 | 防止溫度漂移造成設備過熱、腔體膨脹、薄膜厚度不均或電氣元件損壞等問題 |
三、典型應用領域
| 應用模塊 | 冷卻用途 |
|---|---|
| 腔體冷卻 | 控制反應腔體壁面溫度，避免粒子生成或反應不均 |
| RF 模塊冷卻 | 保持射頻功率器件穩定運行，延長電源和匹配器壽命 |
| 化學液/顯影液冷卻系統 | 穩定液體溫度，控制化學反應速率與晶圓表面處理一致性 |
| 激光/光源組件溫控系統 | 降低光源發熱造成的波長漂移或光強波動，提高圖形成像質量 |
英文資料：
The Tokyo Electron AQA-K09-TYP2 Chiller Unit/Cooling Assembly is a key component of the temperature control system used in TEL semiconductor manufacturing equipment. It is mainly responsible for providing precise temperature regulation and heat exchange functions for process modules such as reaction chambers, light sources, electronic components, etc., to ensure process stability and safe equipment operation.
1、 Basic Product Attributes
Product Name: Chiller/Cooler Unit
Product model: AQA-K09-TYP2
Manufacturer: Tokyo Electron Ltd
Module purpose: Liquid or gas temperature control (may be an internal or external cooling module)
2、 Function and Function
Specific description of functional categories
Temperature control management controls the temperature of process modules, electronic systems, or liquid circuits to maintain it within a predetermined stable range
The heat exchange system utilizes circulating fluids such as refrigerant or DIW (deionized water) to remove heat and achieve continuous cooling
Connect the integrated control interface with the main control system of the equipment (such as PLC or temperature controller) to achieve temperature feedback closed-loop control
The process protection function prevents temperature drift from causing equipment overheating, cavity expansion, uneven film thickness, or damage to electrical components
3、 Typical application areas
Application module cooling purpose
Chamber cooling controls the temperature of the reaction chamber wall to avoid particle generation or uneven reaction
RF module cooling maintains stable operation of RF power devices, extending the lifespan of power supply and matching devices
Chemical/developer cooling system stabilizes liquid temperature, controls chemical reaction rate and ensures consistency with wafer surface treatment
The temperature control system of laser/light source components reduces wavelength drift or light intensity fluctuations caused by light source heating, and improves the quality of graphic imaging
2.產 品 展 示
