Siemens 6ES7317-2FK14-0AB0 中央處理單元
1.產 品 資 料 介 紹：
中文資料：
Siemens 6ES7317-2FK14-0AB0 是西門子 S7-300 系列中的一款強性能中央處理單元（CPU），型號為 CPU 317-2 PN/DP，具有良好的處理能力、集成以太網（PROFINET）與 PROFIBUS 接口，適用于中大型自動化控制系統。
一、產品概述
| 項目 | 說明 |
|---|---|
| 產品型號 | 6ES7317-2FK14-0AB0 |
| 產品名稱 | SIMATIC S7-300 CPU 317-2 PN/DP 中央處理單元 |
| 系列 | SIMATIC S7-300 |
| 制造商 | Siemens（西門子） |
| CPU 類型 | CPU 317-2 PN/DP |
| 應用領域 | 中大型 PLC 控制系統，工廠自動化、過程控制、電力、交通等 |
| 參數 | 數據說明 |
|---|---|
| 處理器性能 | 中等偏上，適用于復雜控制任務 |
| 工作存儲器 | 1 MB（負載存儲器）/ 256 KB（工作存儲器） |
| 指令執行時間 | 位操作約 0.06 μs，字操作約 0.1 μs |
| 數字 I/O 點數支持 | 可通過模塊擴展，支持大量數字量輸入/輸出 |
| 模擬 I/O | 通過擴展模塊支持 |
| 通信端口 | - 1 × PROFINET（帶 RJ45 接口） - 1 × PROFIBUS DP 主站/從站 |
| 通訊協議 | MPI, PROFIBUS DP, PROFINET IO |
| 時鐘 | 內置實時時鐘 |
| 編程語言 | LAD, FBD, STL, SCL, Graph |
| 最大模塊數 | 可擴展至 32 個模塊（需搭配合適電源/擴展機架） |
| 電源電壓 | 24 V DC |
| 尺寸 (寬×高×深) | 80 × 125 × 130 mm |
| 安裝方式 | DIN 導軌安裝 |
| 工作溫度 | 0～60°C |
英文資料：
Siemens 6ES7317-2FK14-0AB0 is a high-performance central processing unit (CPU) in the Siemens S7-300 series, with the model number CPU 317-2 PN/DP. It has good processing capabilities, integrated Ethernet (PROFINET) and PROFIBUS interfaces, and is suitable for medium to large automation control systems.
1、 Product Overview
Project Description
Product model 6ES7317-2FK14-0AB0
Product Name SIMATIC S7-300 CPU 317-2 PN/DP Central Processing Unit
Series SIMATIC S7-300
Manufacturer Siemens
CPU type: CPU 317-2 PN/DP
Large scale PLC control systems in application fields such as factory automation, process control, power, transportation, etc
2、 Main technical parameters
Parameter Data Description
The processor performance is above average and suitable for complex control tasks
Work memory 1 MB (load memory)/256 KB (work memory)
Instruction execution time bit operation is about 0.06 μ s, word operation is about 0.1 μ s
Digital I/O point support can be expanded through modules, supporting a large number of digital inputs/outputs
Simulated I/O supported through expansion modules
Communication port -1 x PROFINET (with RJ45 interface)
-1 x PROFIBUS DP master/slave
Communication protocols MPI, PROFIBUS DP, PROFINET IO
Built in real-time clock
Programming languages LAD, FBD, STL, SCL, Graph
The maximum number of modules can be expanded to 32 (with appropriate power supply/expansion rack)
Power supply voltage 24 V DC
Dimensions (width x height x depth) 80 x 125 x 130 mm
Installation method: DIN rail installation
Working temperature 0-60 ° C
2.產 品 展 示
