GE 193X256AAG01放大器卡
1.產 品 資 料 介 紹:
中文資料:
193X256AAG01 放大器卡 是 GE(General Electric)193X 系列中的一款放大器模塊,設計用于工業自動化控制系統中的信號放大和處理。它提供了高效的信號增強功能,能夠?qū)ξ⑷醯妮斎胄盘栠M(jìn)行放大,使其達到適合后續處理或控制系統的水平。
產品概述
193X256AAG01 放大器卡通常應用于信號處理系統中,能夠?qū)碜詡鞲衅骰蚱渌斎朐O(shè)備的微弱信號進行放大,確保信號在系統中傳輸時不受到噪聲或干擾影響。該卡具有良好的抗干擾性能和高增益特性,適合需要精密信號處理的工業環境。
主要功能
信號放大:用于放大來自外部傳感器、設備或其他模塊的弱電信號。
信號調節:提供增益調整功能,確保信號放大后符合系統要求。
噪聲抑制:內置噪聲抑制功能,有效減少外界干擾,確保信號的質量。
高精度增益:具有高精度的增益控制能力,可以對各種信號進行精確放大。
與其他模塊兼容:可以與 GE 系列的其他模塊協同工作,支持多種類型的信號輸入輸出接口。
技術規格
電源要求:通常由主控制系統提供,可能為 ±15V DC 或 24V DC。
輸入信號類型:模擬電壓或電流信號(例如,0-10V、4-20mA)。
輸出信號類型:經過放大的模擬信號,符合系統要求的標準輸出信號。
溫度范圍:-20°C 至 +70°C。
信號增益:增益調節范圍通常為 1-1000 倍,具體根據應用需求而定。
工作環境:適合工業環境,具有抗電磁干擾和抗震動的能力。
安裝類型:標準插卡式設計,便于安裝和更換。
應用領域
工業自動化:在自動化控制系統中用于增強傳感器信號,確保系統穩定運行。
精密測量與控制系統:用于放大微弱信號,進行精密測量和控制。
過程控制:在生產線、化工廠等場所用于放大過程信號,以實現精確控制。
數據采集系統:信號放大器可用于數據采集系統,確保采集到的信號符合處理標準。
儀器儀表:在各類儀器儀表中用于信號增強,提升測量精度。
英文資料:
The 193X256AAG01 amplifier card is an amplifier module in the GE (General Electric) 193X series, designed for signal amplification and processing in industrial automation control systems. It provides efficient signal enhancement function, which can amplify weak input signals to a level suitable for subsequent processing or control systems.
product overview
The 193X256AAG01 amplifier card is commonly used in signal processing systems to amplify weak signals from sensors or other input devices, ensuring that the signals are not affected by noise or interference during transmission in the system. This card has good anti-interference performance and high gain characteristics, making it suitable for industrial environments that require precision signal processing.
major function
Signal amplification: used to amplify weak electrical signals from external sensors, devices, or other modules.
Signal adjustment: Provides gain adjustment function to ensure that the amplified signal meets the system requirements.
Noise suppression: Built in noise suppression function effectively reduces external interference and ensures signal quality.
High precision gain: With high-precision gain control capability, it can accurately amplify various signals.
Compatible with other modules: It can work together with other modules in the GE series and support multiple types of signal input and output interfaces.
technical specifications
Power requirements: Usually provided by the main control system, it may be ± 15V DC or 24V DC.
Input signal type: Analog voltage or current signal (e.g. 0-10V, 4-20mA).
Output signal type: An amplified analog signal that meets the standard output signal requirements of the system.
Temperature range:- 20 ° C to+70 ° C.
Signal gain: The gain adjustment range is usually 1-1000 times, depending on the application requirements.
Work environment: Suitable for industrial environments, with the ability to resist electromagnetic interference and vibration.
Installation type: Standard plug-in card design, easy to install and replace.
application area
Industrial automation: Used in automation control systems to enhance sensor signals and ensure stable system operation.
Precision measurement and control system: used to amplify weak signals for precise measurement and control.
Process control: Used in production lines, chemical plants, and other places to amplify process signals for precise control.
Data acquisition system: Signal amplifiers can be used in data acquisition systems to ensure that the collected signals meet processing standards.
Instrumentation: Used for signal enhancement and improving measurement accuracy in various types of instruments and meters.
2.產 品 展 示
