GE 193X224ACG01輔助功能板
1.產 品 資 料 介 紹：
中文資料：
193X224ACG01 輔助功能板
產品概述
193X224ACG01 輔助功能板是 GE（通用電氣）為其控制系統設計的模塊，旨在提供輔助控制、信號處理和擴展功能。它用于支持主控制模塊，提供額外的電源調節、信號轉換以及系統保護等功能，確保工業控制系統的穩定性和高效性。
主要功能
信號轉換與調節：能夠調節輸入輸出信號，保證信號的穩定性與準確性。
電源支持：作為電源管理模塊，輔助主電源模塊提供額外的電力支持。
故障檢測與報警：能夠?qū)崟r(shí)監控系統狀態，并提供故障報警功能，幫助快速診斷問題。
擴展接口：為控制系統提供額外的輸入輸出端口，增加系統的擴展性。
保護功能：具備過載保護、過壓保護和過溫保護等，確保系統的安全運行。
技術規格
輸入電壓：支持 AC 或 DC 輸入，符合工業控制系統的標準電壓要求。
輸出電壓：根據需要提供穩定的電源輸出，適應各種設備的需求。
工作溫度：工作溫度范圍一般為 -20°C 至 +60°C，適應工業環境。
尺寸與安裝：符合標準工業尺寸，便于安裝在機架內與其他模塊集成。
保護機制：內置多重保護設計，包括電流過載、過電壓以及高溫保護，確保模塊長期可靠運行。
應用領域
工業自動化控制系統
電力管理與監控系統
生產線自動化設備
發電廠及能源行業控制系統
GE 控制平臺中的輔助功能模塊
英文資料：
193X224ACG01 auxiliary function board
product overview
The 193X224ACG01 auxiliary function board is a module designed by GE (General Electric) for its control system, aimed at providing auxiliary control, signal processing, and expansion functions. It is used to support the main control module, provide additional functions such as power regulation, signal conversion, and system protection, ensuring the stability and efficiency of industrial control systems.
major function
Signal conversion and adjustment: capable of adjusting input and output signals to ensure signal stability and accuracy.
Power support: As a power management module, the auxiliary main power module provides additional power support.
Fault detection and alarm: It can monitor the system status in real time and provide fault alarm function to help diagnose problems quickly.
Expansion interface: Provides additional input and output ports for the control system, increasing the system's scalability.
Protection function: It has overload protection, overvoltage protection, and over temperature protection to ensure the safe operation of the system.
technical specifications
Input voltage: Supports AC or DC input, meeting the standard voltage requirements of industrial control systems.
Output voltage: Provide stable power output as needed to meet the needs of various devices.
Working temperature: The working temperature range is generally -20 ° C to+60 ° C, suitable for industrial environments.
Size and Installation: Compliant with standard industrial dimensions, easy to install in the rack and integrate with other modules.
Protection mechanism: Built in multiple protection designs, including current overload, overvoltage, and high temperature protection, ensure long-term reliable operation of the module.
application area
industrial automation control system
Power Management and Monitoring System
Production line automation equipment
Power plants and energy industry control systems
Auxiliary Function Modules in GE Control Platform
2.產 品 展 示
