GE DS215UCVBG3A控制模塊
1.產 品 資 料 介 紹：
中文資料：
GE DS215UCVBG3A 控制模塊
產品概述
GE DS215UCVBG3A 是通用電氣 Mark V 系列中的一款工業控制模塊，用于燃?xì)夂驼羝麥u輪機控制系統。它是該系列控制系統的核心組件之一，負責邏輯處理、通信管理、信號采集和控制輸出等關鍵任務。
主要功能
控制邏輯處理
模塊內置處理器，負責接收系統內外部輸入信號，執行程序邏輯，并輸出控制信號到執行元件。數據通信管理
支持與系統中其他控制板或外部監控系統的數據交換，實現多級控制系統的協調聯動。信號輸入輸出處理
支持?jǐn)?shù)字與模擬信號輸入輸出，能直接與各種傳感器、變送器和執行器連接。冗余與容錯機制
支持與其他控制模塊協同運行，具備容錯與冗余特性，提升系統可靠性。系統診斷功能
能進行實時自檢，并通過診斷端口或指示裝置反饋系統狀態信息，便于維護和故障排查。
技術規格
系列平臺：GE Mark V 控制系統
接口標準：兼容 VME 總線
工作電源：由系統供電，無需外接獨立電源
安裝方式：標準機架插入式
工作溫度范圍：零度至七十度
存儲溫度范圍：負四十度至八十五度
模塊尺寸與重量：適用于工業控制機柜標準配置
應用領域
燃?xì)鉁u輪機控制系統
蒸汽渦輪機控制系統
電廠自動化控制平臺
工業過程控制系統
高可靠性要求的能源自動化系統
英文資料：
GE DS215UCVBG3A Control Module
product overview
GE DS215UCVBG3A is an industrial control module in the General Electric Mark V series, used for gas and steam turbine control systems. It is one of the core components of this series of control systems, responsible for key tasks such as logic processing, communication management, signal acquisition, and control output.
major function
Control logic processing
The module is equipped with a built-in processor that is responsible for receiving internal and external input signals of the system, executing program logic, and outputting control signals to the executing components.
Data Communication Management
Support data exchange with other control boards or external monitoring systems in the system, achieving coordinated linkage of multi-level control systems.
Signal input/output processing
Supports digital and analog signal input and output, and can be directly connected to various sensors, transmitters, and actuators.
Redundancy and Fault Tolerance Mechanism
Support collaborative operation with other control modules, with fault tolerance and redundancy features, to enhance system reliability.
System diagnostic function
It can perform real-time self inspection and provide feedback on system status information through diagnostic ports or indicator devices, facilitating maintenance and troubleshooting.
technical specifications
Series platform: GE Mark V control system
Interface standard: compatible with VME bus
Working power supply: powered by the system, no need for an external independent power supply
Installation method: Standard rack insertion type
Working temperature range: 0 ° C to 70 ° C
Storage temperature range: -40 ° C to 85 ° C
Module size and weight: Suitable for standard configuration of industrial control cabinets
application area
Gas turbine control system
Steam turbine control system
Power plant automation control platform
industrial process control system
Energy automation systems with high reliability requirements
2.產 品 展 示
