ALCATEL LUCENT   3HE00229ABAF01以太網模塊

1.產 品 資 料 介 紹：

中文資料：

ALCATEL LUCENT 3HE00229ABAF01 以太網模塊

一、產品簡介

3HE00229ABAF01 是 Alcatel-Lucent 推出的適用于 7450 ESS 系列交換平臺的以太網模塊，通常被稱為 IOM-20G（輸入/輸出模塊），主要用于數據轉發與接口管理。該模塊通過安裝多種類型的 MDA（媒體依賴適配器）卡來提供不同類型的網絡接口。

二、核心參數

• 產品型號：3HE00229ABAF01

• 模塊類型：輸入/輸出模塊（IOM）

• 最大吞吐量：20 Gbps

• 插槽類型：MDA 插卡接口

• 支持設備：Alcatel-Lucent 7450 ESS 系列

• 應用功能：控制轉發面數據流，支持以太網服務接口

三、應用領域

1. 電信運營商骨干網和匯聚層
   用于大流量多業務接入場景，滿足穩定性和高可用性的網絡結構需求。

2. 城域網與企業網中核心設備
   承擔主干數據交換任務，連接多個業務子網和遠端接入點。

3. 多業務承載平臺
   與不同的 MDA 插卡組合，提供千兆/萬兆電口或光口，支持 VLAN、MPLS 等服務。

4. 數據中心網絡接入層
   用作高速數據中心邊緣轉發模塊，適用于虛擬化和分布式架構環境。

四、產品特性

• 支持熱插拔

• 高吞吐量，低延遲

• 與多種 MDA 卡兼容，可靈活配置端口

• 穩定可靠，適用于高強度運行環境

• 支持軟件定義網絡（SDN）架構擴展

英文資料：

ALCATEL LUCENT 3HE00229ABAF01 Ethernet module

Brief introduction

3HE00229ABAF01 is an Ethernet module developed by Alcatel Lucent for the 7450 ESS series switching platform, commonly known as IOM-20G (Input/Output Module), primarily used for data forwarding and interface management. This module provides different types of network interfaces by installing multiple types of MDA (Media Dependency Adapter) cards.

2、 Core parameters

Product model: 3HE00229ABAF01

Module type: Input/Output Module (IOM)

Maximum throughput: 20 Gbps

Slot type: MDA card insertion interface

Supported devices: Alcatel Lucent 7450 ESS series

Application function: Control the data flow of the forwarding surface and support Ethernet service interfaces

3、 Application Fields

Telecom operator backbone network and aggregation layer

Used for high traffic and multi service access scenarios, meeting the network architecture requirements of stability and high availability.

Core equipment in metropolitan area networks and enterprise networks

Undertake the task of backbone data exchange, connecting multiple business subnets and remote access points.

Multi service carrier platform

Combined with different MDA card combinations, it provides gigabit/ten gigabit electrical or optical ports and supports services such as VLAN and MPLS.

Data center network access layer

Used as a high-speed data center edge forwarding module, suitable for virtualization and distributed architecture environments.

4、 Product Features

Supports hot swapping

High throughput, low latency

Compatible with multiple MDA cards, allowing for flexible port configuration

Stable and reliable, suitable for high-intensity operating environments

Support software defined network (SDN) architecture extension

2.產      品      展      示
