ALCATEL LUCENT   3HE03612AA端口模塊

1.產 品 資 料 介 紹：

中文資料：

ALCATEL LUCENT 3HE03612AA 端口模塊說明

一、產品概述

型號：3HE03612AA
名稱：MDA-7750 20-PT GE MDA-XP-SFP
該模塊是 Alcatel-Lucent 為其 7750 SR 系列高性能服務路由器設計的擴展端口模塊，提供高密度的千兆以太網接入能力，廣泛應用于運營商網絡、企業網絡和數據中心環境中。

二、技術參數

• 接口數量：20 個千兆以太網端口

• 接口類型：SFP 插槽（支持熱插拔）

• 支持速率：1 Gbps（千兆）

• 模塊類型：MDA（媒體依賴適配器）擴展模塊

• 協議支持：以太網第二層（L2）交換功能，支持 VLAN、QoS 等網絡功能

• 兼容平臺：Alcatel-Lucent 7750 SR 系列服務路由器

三、應用領域

1. 電信運營商核心網絡

   • 提供高密度 GE 接口，用于大容量業務承載與數據轉發

   • 應用于語音、視頻、數據等多業務匯聚網絡

2. 城域網匯聚層

   • 部署在接入層與核心層之間，完成大規模以太網流量整合

   • 實現冗余備份、負載均衡和網絡隔離功能

3. 數據中心互聯（DCI）

   • 支持多種類型 SFP 光模塊，滿足不同距離連接要求

   • 實現數據中心之間的高速光纖互聯

4. 大型企業園區網絡

   • 用于構建高帶寬、低延遲的企業核心網絡

   • 滿足大規模終端及服務器的并發接入需求

英文資料：

ALCATEL LUCENT 3HE03612AA Port Module Description

1、 Product Overview

Model: 3HE03612AA

name: MDA-7750 20-PT GE MDA-XP-SFP

This module is an expansion port module designed by Alcatel Lucent for its 7750 SR series high-performance service router, providing high-density Gigabit Ethernet access capability and widely used in operator networks, enterprise networks, and data center environments.

2、 Technical parameters

Number of interfaces: 20 Gigabit Ethernet ports

Interface type: SFP slot (supports hot swapping)

Supported speed: 1 Gbps (Gigabit)

Module type: MDA (Media Dependency Adapter) extension module

Protocol support: Ethernet Layer 2 (L2) switching function, supporting VLAN, QoS and other network functions

Compatible platform: Alcatel Lucent 7750 SR series service router

3、 Application Fields

Core network of telecommunications operators

Provide high-density GE interfaces for high-capacity business carrying and data forwarding

Applied to multi service aggregation networks such as voice, video, and data

Metropolitan Area Network Aggregation Layer

Deploy between the access layer and the core layer to complete large-scale Ethernet traffic integration

Implement redundant backup, load balancing, and network isolation functions

Data Center Interconnection (DCI)

Supports multiple types of SFP optical modules to meet different distance connection requirements

Realize high-speed fiber optic interconnection between data centers

Large enterprise park network

Used to build high bandwidth, low latency enterprise core networks

Meet the concurrent access requirements of large-scale terminals and servers

2.產      品      展      示
