AMAT  1007-0016控制器模塊

1.產 品 資 料 介 紹：

中文資料：

AMAT 1007-0016 控制器模塊技術說明

1. 基本信息

• 型號：1007-0016

• 制造商：Applied Materials（應用材料公司）

• 設備類型：半導體設備專用控制器

• 適用設備：主要應用于200mm/300mm晶圓處理系統

2. 核心功能

• 設備主控制系統核心組件

• 負責設備邏輯控制和時序管理

• 與各子系統（傳輸/工藝/檢測）通信協調

3. 典型應用

• 晶圓傳輸系統控制

• 工藝設備時序管理

• 設備安全聯鎖控制

4. 技術特點

• 采用實時操作系統（VxWorks）

• 支持SECS/GEM通信協議

• 內置設備狀態監控功能

• 雙冗余電源設計

5. 維護要點

1. 日常檢查：

   • 確認狀態指示燈（LED）正常

   • 檢查散熱風扇運轉情況

   • 記錄控制器運行日志

2. 故障處理：

   • 發生故障時優先保存系統日志

   • 檢查背板連接器接觸狀態

   • 驗證供電電源穩定性（24VDC ±5%）

3. 更換步驟：

   • 停機后斷開所有連接線

   • 記錄原有跳線設置

   • 新模塊需加載備份配置文件

英文資料：

AMAT 1007-0016 Controller Module Technical Description

1. Basic information

Model: 1007-0016

Manufacturer: Applied Materials

Equipment type: Semiconductor equipment dedicated controller

Applicable equipment: mainly used in 200mm/300mm wafer processing systems

2. Core functions

Core components of the equipment main control system

Responsible for equipment logic control and timing management

Coordinate communication with various subsystems (transmission/process/detection)

3. Typical applications

Wafer transfer system control

Process equipment timing management

Equipment safety interlock control

4. Technical features

Adopting real-time operating system (VxWorks)

Support SECS/GEM communication protocol

Built in device status monitoring function

Dual redundant power supply design

5. Maintenance points

Daily inspection:

Confirm that the status indicator light (LED) is functioning properly

Check the operation of the cooling fan

Record the operation log of the controller

Fault handling:

Prioritize saving system logs in the event of a malfunction

Check the contact status of the backplane connector

Verify the stability of the power supply (24VDC ± 5%)

Replacement steps:

Disconnect all connecting wires after shutdown

Record the original jumper settings

New module needs to load backup configuration file
