ALCATEL LUCENT 3CM03285MP交換板
1.產 品 資 料 介 紹：
中文資料：
ALCATEL-LUCENT 3CM03285MP 交換板技術規格
1. 產品概述
型號：3CM03285MP
類型：高性能交換矩陣板
定位：用于阿爾卡特朗訊（諾基亞）核心交換設備，提供高容量數據交換能力
2. 核心功能特性
| 特性 | 技術說明 |
|---|---|
| 交換容量 | 3.2Tbps全雙工 |
| 轉發模式 | 基于信元的交換架構 |
| 延遲性能 | <2μs（64字節報文） |
| 冗余設計 | N+1負載分擔架構 |
| 擴展能力 | 支持在線容量升級 |
3. 技術參數
| 參數 | 規格 |
|---|---|
| 背板接口 | 16x200G QSFP-DD |
| 散熱方式 | 液冷+風冷混合散熱 |
| 功耗 | 450W（滿載） |
| 工作溫度 | 5°C ~ 40°C |
| MTBF | >200,000小時 |
4. 典型應用場景
核心路由器交換矩陣
用于7950 XRS核心路由器
支持400G線卡互聯
數據中心骨干交換
構建CLOS架構葉脊網絡
支持ECMP多路徑負載均衡
5G核心網承載
處理UPF用戶面高速交換
支持網絡切片隔離
英文資料：
ALCATEL-LUCENT 3CM03285MP Switch Board Technical Specifications
1. Product Overview
Model: 3CM03285MP
Type: High performance switching matrix board
Positioning: Used for Alcatel Lucent (Nokia) core switching equipment, providing high-capacity data exchange capabilities
2. Core functional features
Characteristic Technical Description
Switching capacity 3.2Tbps full duplex
Forwarding mode based on cell based switching architecture
Delay performance<2 μ s (64 byte message)
Redundant design N+1 load sharing architecture
Expansion capability supports online capacity upgrade
3. Technical parameters
Parameter specifications
Backplane interface 16x200G QSFP-DD
Heat dissipation method: liquid cooling+air cooling mixed heat dissipation
Power consumption 450W (full load)
Working temperature 5 ° C~40 ° C
MTBF >200, 000 hours
4. Typical application scenarios
Core router switching matrix
Used for 7950 XRS core router
Support 400G line card interconnection
Backbone Exchange in Data Centers
Building a CLOS architecture leaf spine network
Support ECMP multi-path load balancing
5G core network carrier
Handling high-speed exchange of UPF user interface
Support network slicing isolation
2.產 品 展 示
