ALCATEL LUCENT 3FE25676BA光學電氣板
1.產 品 資 料 介 紹：
中文資料：
ALCATEL-LUCENT 3FE25676BA 光學電氣板技術規格
1. 產品概述
型號：3FE25676BA
類型：光電混合接口板
定位：用于阿爾卡特朗訊（諾基亞）光傳輸和IP設備，實現光電信號轉換與業務接入
2. 核心功能特性
| 功能 | 技術說明 |
|---|---|
| 光電轉換 | 支持雙向E/O轉換（1310nm/1550nm波長） |
| 接口類型 | 10G SFP+光口 + 1G/10G Base-T電口混合配置 |
| 協議支持 | Ethernet/IP/MPLS，兼容OTN G.709封裝 |
| 業務處理 | 支持L2交換和L3路由功能 |
| 時鐘同步 | 支持SyncE和1588v2(PTP) |
3. 技術參數
| 參數 | 規格 |
|---|---|
| 光接口 | 最大支持8x10G SFP+ |
| 電接口 | 4x10G Base-T (RJ45) |
| 傳輸距離 | 單模40km（SMF） |
| 功耗 | 45W（典型值） |
| 工作溫度 | 0°C ~ 50°C |
4. 典型應用場景
城域接入網
在7350 OLT設備中實現GPON業務匯聚
支持移動回傳(IP-RAN)的混合組網
企業專線服務
提供E1/T1到以太網的業務轉換
支持VPLS和VPWS二層VPN服務
數據中心互聯
用于DCI的短距光互聯（≤10km）
支持VXLAN over 10G以太網
英文資料：
ALCATEL-LUCENT 3FE25676BA Optical and Electrical Board Technical Specifications
1. Product Overview
Model: 3FE25676BA
Type: Optoelectronic Hybrid Interface Board
Positioning: Used for Alcatel Lucent (Nokia) optical transmission and IP equipment to achieve optical to electrical signal conversion and business access
2. Core functional features
Functional Technical Description
Optoelectronic conversion supports bidirectional E/O conversion (1310nm/1550nm wavelength)
Interface type: 10G SFP+optical port+1G/10G Base-T electrical port hybrid configuration
The protocol supports Ethernet/IP/MPLS and is compatible with OTN G.709 encapsulation
Business processing supports L2 switching and L3 routing functions
Clock synchronization supports SyncE and 1588v2 (PTP)
3. Technical parameters
Parameter specifications
The optical interface supports up to 8x10G SFP+
Electrical interface 4x10G Base-T (RJ45)
Transmission distance single-mode 40km (SMF)
Power consumption 45W (typical value)
Working temperature: 0 ° C~50 ° C
4. Typical application scenarios
metropolitan access network
Implementing GPON business aggregation in 7350 OLT equipment
Hybrid networking supporting mobile backhaul (IP-RAN)
Enterprise dedicated line service
Provide E1/T1 to Ethernet business conversion
Support VPLS and VPWS layer 2 VPN services
Data Center Interconnection
Short distance optical interconnect for DCI (≤ 10km)
Support VXLAN over 10G Ethernet
2.產 品 展 示
