ALCATEL LUCENT 3DH03164AAAA發射器模塊

1.產 品 資 料 介 紹：

中文資料：

ALCATEL-LUCENT 3DH03164AAAA 發射器模塊技術解析

1. 產品定位

該模塊屬于光通信發射單元，用于將電信號轉換為光信號（E/O轉換），主要部署在阿爾卡特朗訊光傳輸和寬帶接入設備中，支持高速數據的光纖傳輸。

2. 核心功能特性

3. 典型應用場景

(1) 光傳輸網絡（OTN/DWDM）

• 在1830 PSS平臺中作為客戶側光接口，實現業務信號的光電轉換和波長復用。

• 支持100G/200G相干傳輸系統的子模塊（如用于CFP2光模塊內部）。

(2) 寬帶接入（PON/FTTx）

• 作為GPON OLT的上行光發射模塊，連接城域核心網。

• 在企業專線中提供10G LAN-PHY或WAN-PHY接口。

(3) 數據中心互聯（DCI）

• 用于數據中心交換機（如7750 SR）的短距/長距光互聯，支持SR/LR/ER等標準。

英文資料：

Technical Analysis of ALCATEL-LUCENT 3DH03164AAAA Transmitter Module

1. Product positioning

This module belongs to the optical communication transmission unit, which is used to convert electrical signals into optical signals (E/O conversion). It is mainly deployed in Alcatel Lucent optical transmission and broadband access equipment, supporting high-speed data fiber transmission.

2. Core functional features

Parameter Technical Specifications (Typical Values) Description

Single mode fiber (SMF) suitable for wavelengths of 1310nm/1550nm

Transmission rates of 1G/10G/25G support SDH, Ethernet, and OTN protocols

Transmitting power -3dBm~+5dBm meets Class 1 laser safety standards

Transmission distance of 10km/40km/80km, available in different power versions

Design of interface type SFP+/XFP pluggable optical module

Operating temperature -5 ° C~+70 ° C Industrial grade temperature adaptability

3. Typical application scenarios

(1) Optical Transmission Network (OTN/DWDM)

As a customer side optical interface in the 1830 PSS platform, it achieves optoelectronic conversion and wavelength multiplexing of business signals.

Support submodules for 100G/200G coherent transmission systems (such as those used inside CFP2 optical modules).

(2) Broadband access (PON/FTTx)

As the upstream optical transmission module of GPON OLT, it connects to the metropolitan core network.

Provide 10G LAN-PHY or WAN-PHY interfaces in enterprise dedicated lines.

(3) Data Center Interconnection (DCI)

Used for short/long distance optical interconnection of data center switches (such as 7750 SR), supporting standards such as SR/LR/ER.
