ALCATEL LUCENT 644-0091-001接口板

1.產 品 資 料 介 紹：

中文資料：

一、產品概述

Alcatel-Lucent 644-0091-001 接口板是一種應用于電信系統中的通信擴展模塊，主要用于在通信設備中提供額外的物理接口，完成網絡信號的接入、轉換、分發與管理。其通常用于接入網、傳輸系統、核心路由平臺或無線控制系統中。

二、主要功能

1. 通信接口擴展：
   提供多個物理端口（如以太網、光纖、串口等），用于連接外部網絡設備或其他模塊。

2. 協議適配與數據處理：
   支持對不同通信協議的數據進行適配、轉發和基本處理。

3. 系統管理集成：
   可通過設備主控系統進行管理與狀態監控，部分型號支持熱插拔和遠程故障檢測。

4. 信號轉換與路由：
   在不同速率或類型的信號之間提供轉換橋接功能，如電/光信號轉換、速率匹配等。

三、技術參數（依據同類接口板推測）

• 接口類型：RJ45電口、SFP光口、RS232串口等（具體以設備配置為準）

• 支持協議：以太網（10/100/1000Mbps）、串行通信協議、或?qū)Ｓ猛ㄐ艆f(xié)議

• 安裝方式：標準插槽式，適用于 Alcatel-Lucent 通信設備機架系統

• 電源供電：由主設備統一供電

• 工作溫度：-5°C ~ +55°C

• 管理支持：SNMP、CLI 命令行、NMS 網絡管理系統集成

四、典型應用設備平臺

• Alcatel-Lucent ISAM 系列接入設備

• 7750 SR 系列路由平臺

• 1850 TSS 光傳輸平臺

• 無線基站控制設備（如 BBU/RNC）

• OSS/NMS 網絡管理系統中的物理通信通道

英文資料：

1、 Product Overview

The Alcatel Lucent 644-0091-001 interface board is a communication expansion module used in telecommunications systems. It is mainly used to provide additional physical interfaces in communication devices to complete network signal access, conversion, distribution, and management. It is commonly used in access networks, transmission systems, core routing platforms, or wireless control systems.

2、 Main functions

Communication interface extension:

Provide multiple physical ports (such as Ethernet, fiber optic, serial, etc.) for connecting external network devices or other modules.

Protocol adaptation and data processing:

Support adaptation, forwarding, and basic processing of data from different communication protocols.

System management integration:

It can be managed and monitored through the device control system, and some models support hot plugging and remote fault detection.

Signal conversion and routing:

Provide conversion bridging functions between signals of different rates or types, such as electrical/optical signal conversion, rate matching, etc.

3、 Technical parameters (estimated based on similar interface boards)

Interface types: RJ45 electrical port, SFP optical port, RS232 serial port, etc. (specific to device configuration)

Supporting protocols: Ethernet (10/100/1000Mbps), serial communication protocol, or dedicated communication protocol

Installation method: Standard slot type, suitable for Alcatel Lucent communication equipment rack system

Power supply: Unified power supply from the main equipment

Working temperature:- 5°C ~ +55°C

Management support: SNMP, CLI command line, NMS network management system integration

4、 Typical Application Device Platform

Alcatel Lucent ISAM series access devices

7750 SR series routing platform

1850 TSS Optical Transmission Platform

Wireless base station control equipment (such as BBU/RNC)

Physical Communication Channels in OSS/NMS Network Management System

2.產      品      展      示
