HORNER ELECTRIC HE693ADC405A模擬電壓模塊

1.產 品 資 料 介 紹：

中文資料：

HORNER ELECTRIC HE693ADC405A 是一款用于 Horner Electric 自動化控制系統的 模擬電壓輸入模塊，旨在提供高精度的模擬信號采集和處理功能。該模塊通常用于工業自動化、過程控制等領域，通過將模擬電壓信號轉換為數字信號，幫助控制系統實時監測和控制各種設備。

主要特點：

1. 多通道輸入

   • HE693ADC405A 模塊提供 多個模擬電壓輸入通道，能夠同時接入多個電壓信號，進行多點數據采集。

   • 通常提供 4~8通道輸入，可以實現對多個傳感器或信號源的實時監控。

2. 高分辨率與精度

   • 該模塊具備 高達16位的分辨率，能夠精確地將輸入的模擬電壓信號轉換為數字信號。

   • 精確度高，適用于需要高精度數據采集的應用場景。

3. 寬輸入電壓范圍

   • 支持 多種電壓范圍，例如常見的 0-10V、±10V、0-5V 等，能夠適配多種工業環境中的模擬電壓信號。

   • 可以根據不同的應用需求靈活配置，滿足各種設備的電壓采集需求。

4. 實時數據采集與處理

   • 模塊提供 高速的數據采集，能夠?qū)崟r(shí)獲取輸入信號并進行數字化處理。

   • 支持快速的信號更新與數據傳輸，使控制系統能夠及時響應外部環境的變化。

5. 隔離與抗干擾能力

   • HE693ADC405A 模塊通常采用 信號隔離設計，有效避免了電氣噪聲、干擾等對信號傳輸?shù)挠绊憽?/p>

   • 具備較強的抗干擾能力，適應工業環境中的復雜電磁干擾。

6. 溫度與電源補償

   • 該模塊支持 溫度補償 功能，可以根據溫度變化進行動態調整，確保測量的準確性。

   • 提供 電源補償，保證在不同電源條件下的穩定運行。

7. 可編程功能與靈活配置

   • HE693ADC405A 模塊與 Horner Electric 的其他控制設備兼容，能夠與 PLC 和 HMI 系統進行無縫集成。

   • 通過 Proficy Machine Edition 等編程軟件進行參數配置和調試，支持靈活的用戶定制化需求。

8. 數據可視化與監控

   • 可以通過 HMI 或 SCADA 系統將數據可視化，方便操作員進行實時監控與數據分析。

   • 提供直觀的界面，便于查看每個輸入通道的實時電壓數據。

英文資料：

HORNER ELECTRIC HE693ADC405A is an analog voltage input module used in Horner Electric's automation control system, designed to provide high-precision analog signal acquisition and processing capabilities. This module is commonly used in industrial automation, process control, and other fields. By converting analog voltage signals into digital signals, it helps control systems to monitor and control various devices in real time.

Main features:

Multi channel input

The HE693ADC405A module provides multiple analog voltage input channels, which can simultaneously access multiple voltage signals for multi-point data acquisition.

Usually providing 4-8 channels of input, it can achieve real-time monitoring of multiple sensors or signal sources.

High resolution and precision

This module has a resolution of up to 16 bits and can accurately convert input analog voltage signals into digital signals.

High precision, suitable for application scenarios that require high-precision data collection.

Wide input voltage range

Supports multiple voltage ranges, such as common 0-10V, ± 10V, 0-5V, etc., and can adapt to analog voltage signals in various industrial environments.

It can be flexibly configured according to different application requirements to meet the voltage acquisition needs of various devices.

Real time data collection and processing

The module provides high-speed data acquisition, enabling real-time acquisition of input signals and digital processing.

Support fast signal updates and data transmission, enabling the control system to respond promptly to changes in the external environment.

Isolation and anti-interference capability

The HE693ADC405A module typically adopts a signal isolation design, effectively avoiding the impact of electrical noise, interference, and other factors on signal transmission.

Has strong anti-interference ability and adapts to complex electromagnetic interference in industrial environments.

Temperature and power compensation

This module supports temperature compensation function, which can dynamically adjust according to temperature changes to ensure measurement accuracy.

Provide power compensation to ensure stable operation under different power conditions.

Programmable functionality and flexible configuration

The HE693ADC405A module is compatible with other control devices of Horner Electric and can seamlessly integrate with PLC and HMI systems.

Parameter configuration and debugging are carried out through programming software such as Proficy Machine Edition, supporting flexible user customization needs.

Data Visualization and Monitoring

Data can be visualized through HMI or SCADA systems, facilitating real-time monitoring and data analysis for operators.

Provide an intuitive interface for viewing real-time voltage data for each input channel.

2.產      品      展      示
