HORNER ELECTRIC HE693RTD600M輸入模塊

1.產 品 資 料 介 紹：

中文資料：

HORNER ELECTRIC HE693RTD600M 是一款 RTD（電阻溫度檢測）輸入模塊，用于 GE Fanuc 90-30 PLC 系列，實現溫度信號的采集和處理。它支持多種類型的 RTD 傳感器，廣泛應用于溫度監測、過程控制和工業自動化等領域。

主要特點：

1. 兼容性

   • 專為 GE Fanuc 90-30 PLC 設計，易于集成到現有自動化控制系統中。

   • 兼容 Horner Electric 自動化設備，適用于工業環境中的溫度監測。

2. 輸入通道

   • 提供 6 個 RTD 輸入通道，支持多個 RTD 傳感器同時連接。

3. 支持的 RTD 類型

   • 支持多種常見的 RTD 傳感器類型，包括：

     • Pt100（100Ω 鉑 RTD）

     • Pt1000（1000Ω 鉑 RTD）

     • Ni120（120Ω 鎳 RTD）

     • Cu10（10Ω 銅 RTD）

4. 溫度測量范圍

   • Pt100: -200°C 至 +850°C

   • Pt1000: -200°C 至 +850°C

   • Ni120: -80°C 至 +260°C

   • Cu10: -100°C 至 +260°C

5. 精度與分辨率

   • 分辨率：0.1°C

   • 精度：±0.1%（根據傳感器類型和測量范圍而變化）

6. 冷端補償

   • 采用 自動冷端補償 技術，以提高測量準確性，減少外部溫度變化對測量的影響。

7. 通信與數據傳輸

   • 提供 數字化輸出，可通過 PLC 程序 訪問采集的溫度數據，并進行實時監控與控制。

8. LED 狀態指示

   • 模塊上配有 LED 指示燈，用于顯示輸入狀態、故障警告和運行狀況，便于操作和維護。

英文資料：

HORNER ELECTRIC HE693RTD600M is an RTD (Resistance Temperature Detection) input module used in the GE Fanuc 90-30 PLC series to collect and process temperature signals. It supports multiple types of RTD sensors and is widely used in fields such as temperature monitoring, process control, and industrial automation.

Main features:

compatibility

Specially designed for GE Fanuc 90-30 PLC, easy to integrate into existing automation control systems.

Compatible with Horner Electric automation equipment, suitable for temperature monitoring in industrial environments.

Channel

Provide 6 RTD input channels and support simultaneous connection of multiple RTD sensors.

Supported RTD types

Supports multiple common types of RTD sensors, including:

Pt100 (100 Ω platinum RTD)

Pt1000 (1000 Ω platinum RTD)

Ni120 (120 Ω nickel RTD)

Cu10 (10 Ω copper RTD)

Temperature measurement range

Pt100: -200 ° C to+850 ° C

Pt1000: -200 ° C to+850 ° C

Ni120: -80 ° C to+260 ° C

Cu10: -100 ° C to+260 ° C

Accuracy and Resolution

Resolution: 0.1 ° C

Accuracy: ± 0.1% (varies depending on sensor type and measurement range)

Cold Junction Compensation

Adopting automatic cold end compensation technology to improve measurement accuracy and reduce the impact of external temperature changes on measurement.

Communication and Data Transmission

Provide digital output, which can access the collected temperature data through PLC program and perform real-time monitoring and control.

LED status indication

The module is equipped with LED indicator lights to display input status, fault warnings, and operating conditions for easy operation and maintenance.

2.產      品      展      示
