HORNER ELECTRIC HE693RTD600R輸入模塊
1.產 品 資 料 介 紹：
中文資料：
HORNER ELECTRIC HE693RTD600R 是一款 RTD（電阻溫度檢測）輸入模塊，用于 GE Fanuc 90-30 PLC 系列，實現高精度溫度信號采集。它支持多種 RTD 傳感器，可用于工業自動化過程控制中的溫度監測。
主要特點：
兼容性
適用于 GE Fanuc 90-30 PLC 作為溫度輸入模塊，直接插入 PLC 機架。
兼容 Horner Electric 自動化系統，廣泛應用于溫度測量和控制。
輸入通道
6 個 RTD 傳感器輸入通道，支持多個傳感器同時測量。
支持的 RTD 類型
100Ω 鉑 RTD（Pt100）
120Ω 鎳 RTD（Ni120）
10Ω 銅 RTD（Cu10）
測量范圍
Pt100: -200°C ~ 850°C
Ni120: -80°C ~ 260°C
Cu10: -100°C ~ 260°C
精度與分辨率
分辨率：0.1°C
精度：±0.1% 滿量程
信號處理
自動冷端補償，提高測量準確性。
抗干擾設計，減少工業環境中的電磁噪聲影響。
通信與數據處理
采集的溫度數據可以通過 PLC 邏輯程序 直接訪問。
支持 模擬量數據轉換，用于溫度控制和監測應用。
LED 指示燈
顯示輸入狀態和故障報警，便于維護和故障排除。
應用領域：
工業自動化（生產線溫度監測）
食品加工（溫度控制和記錄）
HVAC 系統（供暖、通風、空調溫度調節）
冶金、化工（過程溫度測量與控制）
英文資料：
HORNER ELECTRIC HE693RTD600R is an RTD (Resistance Temperature Detection) input module used in the GE Fanuc 90-30 PLC series to achieve high-precision temperature signal acquisition. It supports multiple RTD sensors and can be used for temperature monitoring in industrial automation process control.
Main features:
compatibility
Suitable for GE Fanuc 90-30 PLC as a temperature input module, directly inserted into the PLC rack.
Compatible with Horner Electric automation systems, widely used for temperature measurement and control.
Channel
6 RTD sensor input channels, supporting simultaneous measurement by multiple sensors.
Supported RTD types
100 Ω Platinum RTD (Pt100)
120 Ω Nickel RTD (Ni120)
10 Ω Copper RTD (Cu10)
measuring range
Pt100: -200°C ~ 850°C
Ni120: -80°C ~ 260°C
Cu10: -100°C ~ 260°C
Accuracy and Resolution
Resolution: 0.1 ° C
Accuracy: ± 0.1% of full scale
Signal Processing
Automatic cold end compensation improves measurement accuracy.
Anti interference design to reduce the impact of electromagnetic noise in industrial environments.
Communication and Data Processing
The collected temperature data can be directly accessed through the PLC logic program.
Support analog data conversion for temperature control and monitoring applications.
LED indicator light
Display input status and fault alarms for easy maintenance and troubleshooting.
Application areas:
Industrial automation (production line temperature monitoring)
Food processing (temperature control and recording)
HVAC system (heating, ventilation, air conditioning temperature regulation)
Metallurgy and Chemical Industry (Process Temperature Measurement and Control)
2.產 品 展 示
