HORNER ELECTRIC  HE693ADC816模擬輸入模塊

1.產 品 資 料 介 紹：

中文資料：

Horner Electric 的 HE693ADC816 模擬輸入模塊是一款專為工業自動化系統設計的設備，提供 8 個單端模擬輸入通道，并支持 16 位分辨率。它能夠將模擬輸入信號（如電流）轉換為數字值，并將數據傳輸?shù)?PLC 系統，確保準確的數據采集和控制。

主要特點：

• 輸入范圍：支持 ±1mA 的輸入范圍，適合多種應用。

• 采樣率：提供每秒高達 3000 次通道采樣，確保實時數據采集。

• 輸入阻抗：具有 10kΩ 的輸入阻抗，保證信號傳輸?shù)臏蚀_性。

• 模擬濾波功能：內置 1.6kHz 低通濾波器，減少信號噪聲。

• 數字濾波功能：提供 1 至 128 次采樣的數字濾波選項，提高數據的可靠性。

• 高輸入電壓承受能力：能夠承受最大 75VDC 的輸入電壓，增強系統的耐用性。

• 隔離設計：提供 500VDC 的背板隔離，確保系統的安全性。

• 共模抑制：具有超過 100dB 的共模抑制比，確保信號清晰和準確。

• 工作溫度范圍：適用于 0 至 60°C 的工作環境。

應用領域：

1. 工業自動化：實時監測和控制生產線中的關鍵參數，提升生產效率和產品質量。

2. 過程控制：在化工、制藥等行業中用于精確控制生產工藝，確保工藝穩定。

3. 能源管理：優化能源消耗和資源配置，提高能源利用效率。

4. 環境監測：收集環境數據，支持數據分析和決策制定。

HE693ADC816 模塊以其高精度、可靠性和快速采樣能力，廣泛應用于需要精確模擬信號采集和處理的工業場合。

英文資料：

Horner Electric's HE693ADC816 analog input module is a device designed specifically for industrial automation systems, providing 8 single ended analog input channels and supporting 16 bit resolution. It can convert analog input signals (such as current) into digital values and transmit the data to the PLC system, ensuring accurate data acquisition and control.

Main features:

Input range: Supports an input range of ± 1mA, suitable for various applications.

Sampling rate: Provides up to 3000 channel samples per second to ensure real-time data collection.

Input impedance: With an input impedance of 10k Ω, it ensures the accuracy of signal transmission.

Analog filtering function: Built in 1.6kHz low-pass filter to reduce signal noise.

Digital filtering function: Provides digital filtering options from 1 to 128 samples to improve data reliability.

High input voltage tolerance: capable of withstanding a maximum input voltage of 75VDC, enhancing the durability of the system.

Isolation design: Provide 500VDC backplane isolation to ensure system safety.

Common mode rejection: With a common mode rejection ratio exceeding 100dB, it ensures clear and accurate signals.

Working temperature range: suitable for working environments ranging from 0 to 60 ° C.

Application areas:

Industrial automation: Real time monitoring and control of key parameters in the production line to improve production efficiency and product quality.

Process control: Used in industries such as chemical and pharmaceutical to precisely control production processes and ensure process stability.

Energy management: Optimize energy consumption and resource allocation, and improve energy utilization efficiency.

Environmental monitoring: Collect environmental data, support data analysis and decision-making.

The HE693ADC816 module is widely used in industrial applications that require precise analog signal acquisition and processing due to its high precision, reliability, and fast sampling capability.

2.產      品      展      示
