R&S ZNB8矢量網絡分析儀
1.產 品 資 料 介 紹：
中文資料：
R&S ZNB8 矢量網絡分析儀是德國Rohde & Schwarz（R&S）公司生產的一款高性能矢量網絡分析儀（VNA），主要用于射頻（RF）和微波測試，適用于天線、濾波器、放大器、射頻電路、無源/有源器件等的測量。
R&S ZNB8 主要特點
1. 頻率范圍
- 9 kHz 至 8 GHz（支持寬帶測量）。
2. 高精度 & 低噪聲
- 動態范圍：> 140 dB（典型值，10 Hz IF 帶寬）。
- 低跡線噪聲：< 0.004 dB RMS（IF 帶寬 10 kHz 時）。
- 低本底噪聲：-120 dBm，適用于高精度測量。
3. 快速測量速度
- 速度快：測量時間僅需 4 ms（401 點），適用于高吞吐量生產測試。
- 支持多端口測量，可同時測試多個射頻通道，提高效率。
4. 大觸摸屏 & 友好界面
- 配備 12.1 英寸高分辨率觸摸屏，操作直觀。
- 多窗口顯示，支持用戶自定義布局，可同時查看多個參數。
5. 多種端口配置
- 2 端口 / 4 端口可選，支持差分測量，適用于不同應用需求。
- 低插入損耗、出色的源匹配性能，適合高精度測量。
6. 強大測量功能
- S 參數測量（S11、S21、S12、S22），適用于濾波器、放大器等網絡分析。
- 時域分析（TDR），適用于高速信號完整性分析，如 PCB 走線、連接器、封裝等。
- 諧波測量、互調失真（IMD）分析，適用于有源器件測試。
- 脈沖測量，可用于雷達、無線通信等應用。
7. 兼容多種接口
- GPIB、USB、LAN（VXI-11）、SCPI 遠程控制，可集成至自動化測試系統。
- 支持 Python、LabVIEW、MATLAB 編程，方便工程師開發測試方案。
英文資料：
The R&S ZNB8 Vector Network Analyzer is a high-performance Vector Network Analyzer (VNA) produced by Rohde&Schwarz (R&S) in Germany. It is mainly used for radio frequency (RF) and microwave testing, and is suitable for measuring antennas, filters, amplifiers, RF circuits, passive/active devices, etc.
Main features of R&S ZNB8
1. Frequency range
9 kHz to 8 GHz (supports broadband measurement).
2. High precision&low noise
Dynamic range:> 140 dB (typical value, 10 Hz IF bandwidth).
Low trace noise:< 0.004 dB RMS (at an IF bandwidth of 10 kHz).
Low background noise:- 120 dBm, suitable for high-precision measurement.
3. Quickly measure speed
Fast speed: Measurement time only takes 4 ms (401 points), suitable for high-throughput production testing.
Support multi port measurement, capable of testing multiple RF channels simultaneously to improve efficiency.
4. Large touch screen&user-friendly interface
Equipped with a 12.1-inch high-resolution touch screen, the operation is intuitive.
Multi window display, supports user-defined layout, and can view multiple parameters simultaneously.
5. Multiple port configurations
2-port/4-port options are available, supporting differential measurement and suitable for different application requirements.
Low insertion loss, excellent source matching performance, suitable for high-precision measurement.
6. Powerful measurement function
S-parameter measurement (S11, S21, S12, S22), suitable for network analysis of filters, amplifiers, etc.
Time Domain Analysis (TDR) is suitable for high-speed signal integrity analysis, such as PCB routing, connectors, packaging, etc.
Harmonic measurement and intermodulation distortion (IMD) analysis, suitable for active device testing.
Pulse measurement can be used for applications such as radar and wireless communication.
7. Compatible with multiple interfaces
GPIB, USB, LAN (VXI-11), SCPI remote control, can be integrated into automated testing systems.
Supports programming with Python, LabVIEW, and MATLAB, making it convenient for engineers to develop testing solutions.
