GIDINGS&LEWIS 502-03786-00輸入編碼器
1.產 品 資 料 介 紹：
產品概述
技術參數（典型指標，具體以實物為準）
英文資料：
Product Overview
The GIDDINGS&LEWIS 502-03786-00 input encoder module is a critical position and velocity feedback input component in industrial control systems. Its core function is to read the signals emitted by rotary encoders or linear encoders and cleverly convert these signals into data formats that the control system can recognize. In the process of modern industrial production, the precision control of equipment movement is becoming increasingly stringent. With its excellent performance, this module provides extremely accurate motion feedback data for equipment such as machine tools, automated production lines, and robot systems. It is an important guarantee for achieving closed-loop control and high-precision positioning, helping equipment achieve multi axis synchronous control and high-speed motion control, laying a solid foundation for the development of industrial automation towards higher precision and efficiency.
Technical parameters (typical indicators, specific subject to physical object)
Module type: Designed specifically for encoder input, it precisely interfaces with encoder signals in the entire industrial control system, playing a key role in signal relay and conversion.
Number of channels: Supports multi-channel input, with common channel configurations ranging from 4 to 8 channels. The multi-channel design enables the module to simultaneously process signals from multiple encoders. In complex industrial equipment, such as multi axis CNC machine tools, encoder signals from different coordinate axes can be synchronously collected and processed by the module, greatly improving the overall control accuracy and operational efficiency of the equipment.
Supporting encoder types: Whether it is an incremental encoder or an absolute value encoder, the 502-03786-00 input encoder module can be perfectly adapted. The incremental encoder reflects position changes by outputting pulse signals, and the module can accurately capture and analyze these pulses; The absolute value encoder can directly output the absolute value encoding representing the current position at any time, and the module can quickly and accurately read and convert it into position information recognizable by the control system, meeting the diverse requirements of encoder types in different application scenarios.
Input signal level: Compatible with both TTL and HTL level standards, depending on the type of encoder connected. TTL level, with its high-speed and low-power characteristics, is suitable for situations that require high signal transmission speed; HTL level performs well in complex electromagnetic environments due to its stronger anti-interference ability. This module can intelligently recognize and adapt encoder signals of different levels, ensuring the stability and accuracy of signal transmission.
Resolution: Its resolution depends on the connected encoder body and can reach up to 25000 to 50000 PRR (pulses per revolution). High resolution means the ability to measure and provide more precise feedback on the motion position of the equipment. In precision machining equipment, such as CNC machine tools for processing high-precision molds, high-resolution encoder modules can control the position accuracy of the tool within a very small range, ensuring the machining quality of the product.
Sampling speed: With high-speed sampling capability, it can quickly capture changes in encoder signals and fully meet the strict requirements of real-time control. In high-speed automated production lines, the motion state of equipment is constantly changing
