GIDDINGS & LEWIS DSM-130伺服驅動器

1.產 品 資 料 介 紹：

GIDDINGS & LEWIS DSM-130 伺服驅動器詳解

一、核心功能：單軸精密驅動的 “動力核心”

二、技術特點：保障單軸驅動的關鍵性能

• 單軸專注控制：專為單軸驅動設計，控制邏輯更聚焦，可避免多軸干擾，在精密鏜床的主軸驅動中，能將轉速波動控制在 ±0.1% 以內，保證切削表面光潔度。
• 寬電源適配：支持三相 AC 220V/380V/460V 工業電源，通過內部電源轉換電路適應 ±10% 的電壓波動，在電力不穩定的工業環境中仍能穩定輸出，無需額外穩壓設備。
• 中功率精準輸出：適配中功率伺服電機（典型功率范圍 1.5kW-15kW），輸出電流穩定度達 0.5%，可驅動電機在額定負載下持續運行，滿足數控機床進給軸、機器人關節等場景的動力需求。
• 多模式靈活切換：
  • 位置控制：通過脈沖指令實現 ±0.001mm 級定位，適用于精密鉆孔機的孔位控制；
  • 速度控制：支持 0-3000rpm 寬速域調節，轉速精度 ±0.02%，適合印刷機的恒速走紙；
  • 扭矩控制：輸出扭矩誤差≤2%，可用于紡織機械的恒張力卷繞。
• 高兼容性反饋：兼容增量編碼器（如 1024 線）、高分辨率解析器及閉環控制裝置，反饋信號采樣頻率達 1MHz，確保實時捕捉電機運行狀態，為閉環控制提供數據支撐。
• 高速通訊能力：與 G&L 控制器或上位系統采用高速通訊協議（如 EtherCAT），數據傳輸延遲≤1ms，滿足高動態場景下的指令實時交互，例如機器人的快速軌跡修正。
• 全面保護機制：
  • 過壓 / 欠壓保護：當電源電壓超出 110% 或低于 90% 額定值時觸發；
  • 過流保護：輸出電流達額定值 150% 時自動限流；
  • 過熱保護：散熱器溫度超 85℃時降額運行；
  • 編碼器丟失保護：反饋信號中斷后 0.5s 內觸發安全停機，防止設備失控。

英文資料：

GIDINGS&LEWIS DSM-130 servo drive detailed explanation

1、 Core function: The "power core" of single axis precision drive

GIDINGS&LEWIS DSM-130 servo drive, as a high-performance single axis servo drive module, is the "power engine" of CNC machine tools and industrial automation systems. It receives instructions from the upper control system and provides stable power to AC or brushless DC servo motors through precise current and voltage regulation. At the same time, relying on a closed-loop control mechanism, it corrects position, speed, and torque deviations in real time to ensure the accuracy and response speed of the actuator. It is the core executing component for achieving high-precision motion control.

2、 Technical features: Ensuring key performance of single axis drive

Single axis focused control: Designed specifically for single axis drive, the control logic is more focused and can avoid multi axis interference. In the spindle drive of precision boring machines, the speed fluctuation can be controlled within ± 0.1% to ensure the smoothness of the cutting surface.

Wide power supply adaptation: Supports three-phase AC 220V/380V/460V industrial power supply, adapts to ± 10% voltage fluctuations through internal power conversion circuits, and can still output stably in unstable industrial environments without the need for additional voltage stabilization equipment.

Medium power precise output: Suitable for medium power servo motors (typical power range of 1.5kW-15kW), with an output current stability of 0.5%, it can drive the motor to operate continuously under rated load, meeting the power requirements of CNC machine tool feed axes, robot joints and other scenarios.

Multi mode flexible switching:

Position control: ± 0.001mm level positioning is achieved through pulse commands, suitable for hole position control of precision drilling machines;

Speed control: Supports wide speed range adjustment from 0-3000rpm, with a speed accuracy of ± 0.02%, suitable for constant speed paper feeding of printing machines;

Torque control: Output torque error ≤ 2%, can be used for constant tension winding of textile machinery.

High compatibility feedback: compatible with incremental encoders (such as 1024 lines), high-resolution parsers, and closed-loop control devices, with a feedback signal sampling frequency of 1MHz, ensuring real-time capture of motor operating status and providing data support for closed-loop control.

High speed communication capability: It adopts high-speed communication protocol (such as EtherCAT) with G&L controller or upper system, with data transmission delay ≤ 1ms, to meet real-time interaction of instructions in high dynamic scenarios, such as fast trajectory correction of robots.

Comprehensive protection mechanism:

Overvoltage/undervoltage protection: triggered when the power supply voltage exceeds 110% or falls below 90% of the rated value;

Overcurrent protection: Automatic current limiting when the output current reaches 150% of the rated value;

Overheating protection: When the temperature of the radiator exceeds 85 ℃, it will operate at a reduced capacity;

Encoder loss protection: Trigger a safe shutdown within 0.5 seconds after feedback signal interruption to prevent equipment from losing control.
