GE IS230PCAAH1A分析 I/O 組件
1.產 品 資 料 介 紹：
產品名稱
GE IS230PCAAH1A 分析 I/O 組件
（英文描述：GE Mark VIe I/O Pack – IS230PCAAH1A Analog Input Module）
一、產品概述
IS230PCAAH1A 是 GE Mark VIe 控制系統中使用的 模擬輸入 I/O 模塊（I/O Pack），用于采集現場的模擬信號并傳送至控制器（如 Mark VIe 或 Mark VIeS 系統）。該模塊具備高精度、工業級抗干擾能力及系統冗余支持，廣泛部署在 GE 的燃氣輪機、蒸汽輪機、壓縮機及發電廠自動化系統中。
二、技術參數
模塊類型：模擬量輸入模塊（Analog Input I/O Pack）
產品系列：GE Mark VIe / VIeS 控制系統
型號編碼：IS230PCAAH1A
輸入信號類型：
電流輸入（4–20 mA，0–20 mA）
電壓輸入（±5V、±10V）——取決于 I/O Terminal Board 配置
通道數量：通常 10–20 個模擬輸入通道（依連接的終端板類型而定）
通信接口：
與控制器通過 IONet 網絡（冗余 Ethernet）通信
I/O Pack 安裝在終端板上，通過背板連接信號和電源
電源要求：
來自 I/O Terminal Board 的后備電源供電（一般為 28 VDC）
診斷功能：
通道級短路、斷路、自檢診斷
通道狀態指示 LED
支持冗余：支持與雙通道終端板配合實現 I/O 冗余
工作環境：
溫度范圍：-30°C ~ +65°C
工業環境 EMC 抗干擾設計
適配終端板：兼容多個類型的 I/O Terminal Board（如 TBCA、TBCC）
英文資料：
product name
GE IS230PCAAH1A Analysis of I/O Components
(English description: GE Mark VIe I/O Pack - IS230PCAAH1A Analog Input Module)
1、 Product Overview
IS230PCAAH1A is an analog input I/O module (I/O Pack) used in GE Mark VIe control systems to collect analog signals from the field and transmit them to controllers (such as Mark VIe or Mark VIeS systems). This module has high precision, industrial grade anti-interference capability, and system redundancy support, and is widely deployed in GE's gas turbine, steam turbine, compressor, and power plant automation systems.
2、 Technical parameters
Module type: Analog Input I/O Pack
Product Series: GE Mark VIe/VIeS Control System
Model code: IS230PCAAH1A
Input signal type:
Current input (4-20 mA, 0-20 mA)
Voltage input (± 5V, ± 10V) - depends on the I/O Terminal Board configuration
Number of channels: Typically 10-20 analog input channels (depending on the type of terminal board connected)
Communication interface:
Communicate with the controller through IONet network (redundant Ethernet)
I/O Pack is installed on the terminal board and connects signals and power through the backplane
Power requirements:
Backup power supply from I/O Terminal Board (usually 28 VDC)
Diagnostic function:
Channel level short circuit, open circuit, self check diagnosis
Channel status indicator LED
Support redundancy: Supports I/O redundancy in conjunction with dual channel terminal boards
Work environment:
Temperature range: -30 ° C~+65 ° C
EMC anti-interference design for industrial environment
Compatible with multiple types of I/O Terminal Boards (such as TBCA, TBCC)
