GE   193X543ABG02電動電路板

1.產 品 資 料 介 紹：

中文資料：

GE 193X543ABG02 是通用電氣公司（General Electric）193X 系列工業控制系統中的一款關鍵電路板，常被稱為“電動控制板”或“電動電路板”。該模塊廣泛應用于 GE 的直流或交流驅動系統中，用于執行電動設備的控制邏輯，包括電機驅動信號處理、反饋調節、系統保護等功能。

該電路板通常作為整個驅動系統的子功能板，配合主控制板、反饋板、勵磁板等一起運行，確保設備在工業現場的穩定運行。

技術參數與功能特點

• 型號：193X543ABG02

• 產品類型：電動控制電路板（Motor Control PCB）

• 系統適配：GE 193X 系列工業自動化系統

• 安裝方式：標準插卡式安裝，通過金手指接口連接控制框架

• 輸入信號：模擬信號（如電壓反饋、電流反饋）、數字邏輯命令、觸發控制信號

• 輸出信號：控制信號輸出到執行器、驅動器、繼電器等

• 板載元件：集成多個運算放大器、晶體管、調節電位器、電容電阻等分立元器件

• 調節功能：設有電位器用于調節控制增益、響應時間、補償參數等

• 工作電壓：通常為 ±15V DC，需由系統統一供電

• 工作溫度范圍：-20℃ 至 +70℃，適用于工業現場環境

• 狀態顯示：部分版本帶有 LED 狀態指示燈，便于調試與運行監控

應用場景

• GE Mark 系列工業電機控制系統（如 Mark II、IV）

• 大型直流/交流電機驅動設備

• 冶金、石化、電廠、水處理、紙漿造紙等過程控制行業

• 用于執行電動機啟?？刂?、速度調節、狀態反饋處理等任務

• 在舊型 GE 控制系統中的電動子板更換或功能擴展中常被采用

安裝與使用注意事項

1. 安裝前必須斷開系統電源，避免插拔操作中發生短路或電弧

2. 板卡為靜電敏感器件，操作時需佩戴防靜電手環

3. 所有輸入輸出信號應嚴格按系統設計圖紙連接，防止控制邏輯異常

4. 初次運行前可使用萬用表、示波器檢查關鍵測試點的電壓波形和電平

5. 若需調節電位器，應緩慢調節并記錄初始設定，以便回退調試值

6. 推薦每 6–12 個月進行一次維護檢查，重點關注電容老化、焊點松動、接口接觸等問題

英文資料：

GE 193X543ABG02 is a critical circuit board in General Electric's 193X series industrial control systems, often referred to as an "electric control board" or "electric circuit board". This module is widely used in GE's DC or AC drive systems to execute control logic for electric equipment, including motor drive signal processing, feedback regulation, system protection, and other functions.

This circuit board is usually used as a sub functional board of the entire drive system, working together with the main control board, feedback board, excitation board, etc., to ensure the stable operation of the equipment on the industrial site.

Technical parameters and functional characteristics

Model: 193X543ABG02

Product type: Motor Control PCB

System adaptation: GE 193X series industrial automation system

Installation method: Standard card insertion installation, connected to the control framework through a gold finger interface

Input signals: analog signals (such as voltage feedback, current feedback), digital logic commands, trigger control signals

Output signal: Control signal output to actuators, drivers, relays, etc

Onboard components: integrated with multiple operational amplifiers, transistors, adjustable potentiometers, capacitors, resistors, and other standing element devices

Adjustment function: Equipped with a potentiometer for adjusting control gain, response time, compensation parameters, etc

Working voltage: usually ± 15V DC, requiring unified power supply from the system

Working temperature range: -20 ℃ to+70 ℃, suitable for industrial site environment

Status display: Some versions come with LED status indicators for easy debugging and operation monitoring

Application scenarios

GE Mark series industrial motor control system (such as Mark II, IV)

Large DC/AC motor drive equipment

Process control industries such as metallurgy, petrochemicals, power plants, water treatment, pulp and paper manufacturing, etc

Used to perform tasks such as motor start stop control, speed regulation, and status feedback processing

It is often used in the replacement or expansion of electric daughter boards in old GE control systems

Installation and usage precautions

Before installation, the system power must be disconnected to avoid short circuits or arcs during plugging and unplugging operations

The board is a static sensitive device, and an anti-static wristband should be worn during operation

All input and output signals should be strictly connected according to the system design drawings to prevent control logic abnormalities

Before the initial operation, a multimeter and oscilloscope can be used to check the voltage waveform and level of key test points

If the potentiometer needs to be adjusted, it should be slowly adjusted and the initial setting should be recorded in order to roll back the debugging value

It is recommended to conduct maintenance checks every 6-12 months, with a focus on issues such as capacitor aging, loose solder joints, and interface contact

2.產      品      展      示
