GE   193X383ACG01探測器模塊

1.產 品 資 料 介 紹：

中文資料：

GE 193X383ACG01 探測器模塊（Detector Module） 是 GE 193X 系列控制系統中的一種重要部件，專門用于探測和監控工業自動化設備中的信號或參數變化。這款探測器模塊廣泛應用于需要精確監控的場合，能夠有效地檢測物理信號（如溫度、壓力、電流、電壓等），并將這些信號反饋給主控系統，支持實時監控和數據采集。

一、產品概述

• 產品型號：193X383ACG01

• 產品名稱：探測器模塊

• 系列：GE 193X 系列控制模塊

• 功能定位：信號檢測、數據采集、過程監控

• 應用領域：自動化生產線、能源管理、工業控制、電氣設備監測等

二、主要功能

1. 信號探測與采集
   探測器模塊用于實時探測工業環境中的信號變化，如溫度、濕度、壓力、電流等，并將這些信號轉化為可用的數據供系統處理。

2. 實時監控
   提供實時監控功能，能夠隨時反饋設備或環境的變化，幫助操作員及時發現異常，采取適當措施。

3. 報警功能
   當探測到的信號超出設定范圍時，探測器模塊可以通過報警系統提醒操作人員，幫助及時處理潛在問題，避免設備損壞。

4. 多種信號輸入支持
   支持多種不同類型的輸入信號，如模擬信號、數字信號等，能夠兼容不同類型的傳感器，廣泛應用于多種測量任務。

5. 系統集成與兼容性
   可與 GE 193X 系列及其他自動化設備兼容，易于集成到現有的控制系統中，支持無縫數據傳輸和處理。

三、典型技術參數

• 輸入信號類型：模擬信號（如 4–20mA、0–10V）、數字信號（如開關量信號）

• 工作電壓：通常為 24V DC 或 48V DC

• 工作溫度范圍：-10°C 至 +60°C

• 輸出信號類型：探測信號輸出，通常為模擬量或數字量，便于進一步處理

• 功耗：低功耗設計，適用于長時間運行

• 安裝方式：卡件式安裝，適配 GE 193X 系列其他模塊

• 信號精度：高精度信號采集，支持準確的實時監測與報警功能

• 防護等級：適用于工業環境，防塵、防水設計，確保設備在惡劣環境下穩定運行

英文資料：

The GE 193X383ACG01 Detector Module is an important component in the GE 193X series control system, specifically designed to detect and monitor signal or parameter changes in industrial automation equipment. This detector module is widely used in situations that require precise monitoring. It can effectively detect physical signals (such as temperature, pressure, current, voltage, etc.) and feedback these signals to the main control system, supporting real-time monitoring and data acquisition.

1、 Product Overview

Product model: 193X383ACG01

Product Name: Detector Module

Series: GE 193X series control module

Functional positioning: signal detection, data acquisition, process monitoring

Application areas: Automated production lines, energy management, industrial control, electrical equipment monitoring, etc

2、 Main functions

Signal detection and acquisition

The detector module is used to detect real-time signal changes in industrial environments, such as temperature, humidity, pressure, current, etc., and convert these signals into usable data for system processing.

Real time monitoring

Provide real-time monitoring function, which can provide feedback on changes in equipment or environment at any time, helping operators detect abnormalities in a timely manner and take appropriate measures.

Alarm

When the detected signal exceeds the set range, the detector module can alert the operator through the alarm system, helping to promptly address potential issues and avoid equipment damage.

Multiple signal input support

Supports multiple types of input signals, such as analog signals, digital signals, etc., and is compatible with different types of sensors, widely used in various measurement tasks.

System integration and compatibility

Compatible with GE 193X series and other automation equipment, easy to integrate into existing control systems, and supports seamless data transmission and processing.

3、 Typical technical parameters

Input signal type: analog signal (such as 4-20mA, 0-10V), digital signal (such as switch signal)

Working voltage: usually 24V DC or 48V DC

Working temperature range:- 10 ° C to+60 ° C

Output signal type: detection signal output, usually analog or digital, for further processing

Power consumption: Low power design, suitable for long-term operation

Installation method: card type installation, compatible with other modules of GE 193X series

Signal accuracy: high-precision signal acquisition, supporting accurate real-time monitoring and alarm functions

Protection level: Suitable for industrial environments, dustproof and waterproof design, ensuring stable operation of equipment in harsh environments

2.產      品      展      示
