GE IS420UCSBHЗA 以太網交換機模塊
1.產 品 資 料 介 紹：
中文資料：
一、產品基本信息
| 項目 | 說明 |
|---|---|
| 產品型號 | IS420UCSBH3A（GE Mark VIe 系統常用） |
| 制造商 | GE (General Electric) |
| 模塊類型 | 控制器模塊（也包含以太網通信功能） |
| 系列 | Mark VIe 控制系統 – Turbine Control Systems |
二、功能與作用
盡管這個模塊具備以太網通信能力，它不是單純的以太網交換機，而是 GE Mark VIe 控制系統中的 控制處理器模塊（UCSB Controller Module），其主要功能如下：
實時控制器功能：執行汽輪機或發電控制的邏輯與順序控制。
通信能力：具備多個以太網端口（冗余網絡），用于與 I/O 模塊、操作員工作站（HMI）、以及其他 UCS 通信。
以太網通信支持：內置雙冗余以太網端口（ENET1 和 ENET2），支持高速數據通信。
嵌入式控制：運行嵌入式實時操作系統，執行 GE ControlST 配置程序所定義的邏輯。
三、技術參數（IS420UCSBH3A）
| 參數 | 內容 |
|---|---|
| CPU | Intel 處理器，內嵌實時系統 |
| 內存 | 2–4GB（用于控制與數據緩沖） |
| 通信端口 | 2×冗余以太網端口（RJ45）；多個內部高速通信通道 |
| 安裝方式 | 安裝于 GE Mark VIe 控制架（Racks）上 |
| 操作系統 | VxWorks 或 QNX（GE 控制專用） |
| 支持協議 | Modbus TCP/IP、Ethernet/IP、GE Proprietary Protocols |
| 冗余支持 | 支持控制器冗余配置（主/備 UCSB 控制模塊） |
英文資料：
1、 Basic Product Information
Project Description
Product model IS420UCSBH3A (commonly used in GE Mark VIe system)
Manufacturer GE (General Electric)
Module type: Controller module (also includes Ethernet communication function)
Series Mark VIe Control Systems - Turbine Control Systems
2、 Function and Function
Although this module has Ethernet communication capability, it is not simply an Ethernet switch, but a control processor module (UCSB Controller Module) in the GE Mark VIe control system. Its main functions are as follows:
Real time controller function: Perform logical and sequential control of steam turbine or power generation control.
Communication capability: Equipped with multiple Ethernet ports (redundant network) for communication with I/O modules, operator workstations (HMI), and other UCSs.
Ethernet communication support: Built in dual redundant Ethernet ports (ENET1 and ENET2), supporting high-speed data communication.
Embedded control: Run an embedded real-time operating system and execute the logic defined by the GE ControlST configuration program.
3、 Technical parameters (IS420UCSBH3A)
Parameter content
CPU Intel processor, embedded with real-time system
Memory 2-4GB (for control and data buffering)
2 communication ports x redundant Ethernet ports (RJ45); Multiple internal high-speed communication channels
Installation method: Install on GE Mark VIe control racks
Operating system VxWorks or QNX (GE control specific)
Supports Modbus TCP/IP protocol Ethernet/IP、GE Proprietary Protocols
Redundancy support supports controller redundancy configuration (primary/backup UCSB control modules)
