ABB DS3800HMPK1K1K 控制器模塊
1.產 品 資 料 介 紹：
產品名稱
GE DS3800HMPK1K1K 控制器模塊
一、產品概述
DS3800HMPK1K1K 是通用電氣（General Electric, GE）公司 Mark IV 系列控制系統中的一款控制器模塊。該模塊廣泛用于 GE 的渦輪控制系統（如燃?xì)廨啓C(jī)或蒸汽輪機控制），用于實現精確的監測、控制和數據處理功能。該型號主要作為主處理模塊之一，集成了微處理器、內存和數據通信功能，用于在控制系統中執行關鍵的控制任務。
二、技術參數
產品系列：GE Speedtronic Mark IV
模塊編號：DS3800HMPK1K1K
功能類型：主控制處理器模塊（Microprocessor Board）
接口特性：
多個插針排
匹配 GE Backplane 總線連接
支持現場數據采集和執行邏輯指令
芯片配置：集成高性能微處理器（Motorola 或 Intel 系列）
內存支持：板載靜態RAM和EPROM芯片，用于固件加載及數據緩存
診斷功能：帶故障自檢（LED 狀態指示）
尺寸規格：標準 6U 插板尺寸，適用于 GE 控制系統機架
英文資料：
product name
GE DS3800HMPK1K1K Controller Module
1、 Product Overview
DS3800HMPK1K1K is a controller module in the Mark IV series control system of General Electric (GE). This module is widely used in GE's turbine control systems (such as gas turbine or steam turbine control) to achieve precise monitoring, control, and data processing functions. This model mainly serves as one of the main processing modules, integrating microprocessor, memory, and data communication functions, used to perform critical control tasks in the control system.
2、 Technical parameters
Product Series: GE Speedtronic Mark IV
Module Number: DS3800HMPK1K1K
Function type: Main control processor module (Microprocessor Board)
Interface features:
Multiple pin banks
Match GE Backplane bus connection
Support on-site data collection and execution of logical instructions
Chip configuration: Integrated high-performance microprocessor (Motorola or Intel series)
Memory support: onboard static RAM and EPROM chips for firmware loading and data caching
Diagnostic function: with fault self check (LED status indication)
Size specification: Standard 6U plug-in board size, suitable for GE control system rack
