TRICONEX 7400213-100 處理器模塊

1.產 品 資 料 介 紹：

中文資料：

TRICONEX 7400213-100 處理器模塊 是 TRICONEX 系列控制系統中的關鍵組件，主要用于提供系統的核心計算能力，并承擔數據處理、控制決策和實時監控等任務。它是 TRICONEX 安全控制系統的基礎，廣泛應用于需要高可靠性和安全性的工業自動化領域。

主要特點

• 三重冗余（TMR）設計
  TRICONEX 7400213-100 采用三重冗余（TMR）架構，這意味著它包含三個獨立的處理單元，確保在單個處理單元發生故障時，其他兩個單元能夠接管工作，從而保證系統持續穩定運行。

• 高性能計算能力
  配備高性能處理器，能夠執行復雜的控制和計算任務，支持實時數據采集、處理和反饋，適應各種復雜的工業應用需求。

• 多協議支持
  支持多種工業協議（如 Modbus、Ethernet/IP、Profibus DP 等），方便與不同類型的設備、控制系統和外圍設備進行無縫連接。

• 高安全性和可靠性
  符合 SIL 3 安全認證標準，確保該模塊在高安全性要求的環境中可靠運行，特別適用于油氣、化工、電力等對安全性有嚴格要求的行業。

• 故障診斷功能
  內置強大的故障檢測和診斷功能，能夠實時監控系統狀態，快速定位故障源并提供詳細的診斷信息，幫助運維人員及時處理問題，減少系統停機時間。

• 遠程監控和控制
  支持遠程監控和控制功能，便于通過網絡實現對系統的遠程管理和操作，提升系統的可維護性和靈活性。

技術規格

英文資料：

The TRICONEX 7400213-100 processor module is a key component in the TRICONEX series control system, mainly used to provide the core computing power of the system and undertake tasks such as data processing, control decision-making, and real-time monitoring. It is the foundation of the TRICONEX safety control system, widely used in industrial automation fields that require high reliability and safety.

main features

Triple Redundancy (TMR) Design

The TRICONEX 7400213-100 adopts a Triple Redundancy (TMR) architecture, which means it contains three independent processing units to ensure that in the event of a single processing unit failure, the other two units can take over the work, thereby ensuring the continuous and stable operation of the system.

High performance computing capability

Equipped with high-performance processors, capable of executing complex control and computing tasks, supporting real-time data acquisition, processing, and feedback, and adapting to various complex industrial application requirements.

Multi protocol support

Supports multiple industrial protocols (such as Modbus, Ethernet/IP, Profibus DP, etc.) for seamless connection with different types of devices, control systems, and peripheral devices.

High security and reliability

Compliant with SIL 3 safety certification standards, this module ensures reliable operation in environments with high safety requirements, especially suitable for industries with strict safety requirements such as oil and gas, chemical, and power.

Fault diagnosis function

Built in powerful fault detection and diagnosis functions can monitor the system status in real-time, quickly locate the fault source, and provide detailed diagnostic information to help operation and maintenance personnel handle problems in a timely manner and reduce system downtime.

Remote monitoring and control

Support remote monitoring and control functions, facilitate remote management and operation of the system through the network, and enhance the maintainability and flexibility of the system.

technical specifications

Project parameter description

Processor type: High performance real-time processor

Redundancy Type Triple Redundancy (TMR)

Working voltage 24V DC

Environmental temperature range -20 ° C to+60 ° C

Safety certification SIL 3

Communication protocols support Modbus, Ethernet/IP, Profibus, etc

Installation method: DIN rail installation

2.產      品      展      示
