AMAT Applied Materials  0100-00206 PCB組件

1.產 品 資 料 介 紹：

AMAT Applied Materials 0100-00206 PCB 組件

核心功能

• 信號集中處理：集成運算放大器、濾波器和邏輯電路，實現多通道模擬 / 數字信號的調理與轉換
• 電源管理：提供多路隔離電源輸出（5V、12V、24V），為周邊傳感器和執行器供電
• 接口轉換：實現不同電平信號（TTL/CMOS/RS-485）的轉換與適配
• 系統互聯：作為中間轉接板，連接主控制器與各類功能模塊
• 狀態監測：集成故障檢測電路，實時監控電源和信號狀態

技術特點

典型應用

• 半導體刻蝕設備的傳感器信號采集與處理
• 沉積設備的執行器控制信號分配
• 真空系統的狀態監測與控制信號轉接
• 工藝腔室周邊輔助設備的協調控制

AMAT Applied Materials 0100-00206 PCB組件 英文資料：

AMAT Applied Materials 0100-00206 PCB Components

AMAT 0100-00206 is a multi-layer printed circuit board component designed specifically for semiconductor manufacturing equipment, integrating signal processing, power distribution, and interface conversion functions as the core connection and control hub between device subsystems.

core functionality

Centralized signal processing: integrating operational amplifiers, filters, and logic circuits to achieve conditioning and conversion of multi-channel analog/digital signals

Power Management: Provides multiple isolated power outputs (5V, 12V, 24V) to power surrounding sensors and actuators

Interface conversion: realize the conversion and adaptation of different level signals (TTL/CMOS/RS-485)

System interconnection: As an intermediate adapter board, it connects the main controller with various functional modules

Status monitoring: Integrated fault detection circuit, real-time monitoring of power and signal status

Technical Features

Project specifications

6-8 layer structure high-density PCB design

Working temperature -10 ℃~60 ℃

Supply voltage 24VDC (± 10%)

Signal channels 16-32 analog inputs/outputs

32-64 channels of digital input/output

Isolation level: 2.5kVrms between signals, 5kVrms between power supply and signals

Size specification standard 160 × 100mm (customizable)

Connector type: high-density needle socket combined with Phoenix terminal

Protection design with moisture-proof and anti-corrosion coating treatment

Typical Applications

Sensor signal acquisition and processing of semiconductor etching equipment

Distribution of actuator control signals for sedimentation equipment

Status monitoring and control signal switching of vacuum system

Coordination and control of auxiliary equipment around the process chamber
