ABB   AAI141-H50 S2模擬 I/O 模塊

1.產 品 資 料 介 紹：

中文資料：

橫河電機 (Yokogawa) AAI141-H50 S2 是一款高性能的模擬輸入/輸出 (I/O) 模塊，廣泛應用于過程控制和工業自動化系統中，特別是在橫河 Centum 和 ProSafe 系列 DCS 系統中。該模塊為模擬信號的采集和處理提供可靠支持，適用于各種復雜工業場景。

主要特點：

1. 高精度模擬輸入/輸出支持：

   • 提供多個通道的模擬信號處理能力，可支持標準工業信號（如 4-20 mA 或 0-10 V）。

2. 模塊化設計：

   • 可插拔模塊化設計，便于安裝、拆卸和更換。
   • 支持系統擴展，適應不同的應用需求。

3. 可靠性和耐久性：

   • 采用工業級元件，具備抗電磁干擾 (EMI) 和抗震動能力，適合在苛刻環境下使用。

4. 實時數據處理：

   • 低延遲數據傳輸和高采樣速率，滿足對實時性要求較高的工業控制場景。

5. 集成診斷功能：

   • 支持實時監測和故障診斷，便于用戶及時發現并處理問題。
   • 提供通道狀態指示燈，直觀顯示模塊運行狀態。

6. 兼容性：

   • 與橫河控制系統無縫集成，同時支持與其他標準自動化設備協作。

技術規格（部分）：

• 型號：AAI141-H50 S2
• 通道數：支持多路輸入/輸出（具體通道數需參考詳細技術文檔）
• 信號類型：
  • 輸入：4-20 mA、0-10 V 等標準模擬信號
  • 輸出：4-20 mA（可選）
• 精度：高精度，典型誤差在 0.1% 或更低
• 供電電壓：24 VDC
• 工作溫度：-20°C 至 +70°C
• 安裝方式：DIN 導軌或機架安裝
• 通信接口：支持與控制系統的標準通信協議
• 防護等級：IP20（適合控制柜內使用）

英文資料：

Yokogawa AAI141-H50 S2 is a high-performance analog input/output (I/O) module widely used in process control and industrial automation systems, particularly in Yokogawa Centum and ProSafe series DCS systems. This module provides reliable support for the acquisition and processing of analog signals and is suitable for various complex industrial scenarios.

Main features:

High precision analog input/output support:

Provides analog signal processing capabilities for multiple channels, supporting standard industrial signals such as 4-20 mA or 0-10 V.

Modular design:

Pluggable modular design for easy installation, disassembly, and replacement.

Support system expansion to adapt to different application requirements.

Reliability and Durability:

Using industrial grade components with anti electromagnetic interference (EMI) and anti vibration capabilities, suitable for use in harsh environments.

Real time data processing:

Low latency data transmission and high sampling rate meet the high real-time requirements of industrial control scenarios.

Integrated diagnostic function:

Support real-time monitoring and fault diagnosis, facilitating users to discover and handle problems in a timely manner.

Provide channel status indicator lights to visually display the operating status of the module.

compatibility:

Seamless integration with Yokogawa control system, while supporting collaboration with other standard automation equipment.

Technical specifications (partial):

model: AAI141-H50 S2

Number of channels: Supports multiple input/output channels (specific number of channels should refer to detailed technical documentation)

Signal type:

Input: Standard analog signals such as 4-20 mA and 0-10 V

Output: 4-20 mA (optional)

Accuracy: High precision, with a typical error of 0.1% or lower

Supply voltage: 24 VDC

Working temperature:- 20 ° C to+70 ° C

Installation method: DIN rail or rack installation

Communication Interface: Supports standard communication protocols with control systems

Protection level: IP20 (suitable for use inside control cabinets)

2.產      品      展      示
