GIDINGS&LEWIS 502-03518-03模擬輸出模塊
1.產 品 資 料 介 紹：
產品概述
技術參數
英文資料：
Product Overview
As an important component of the PiC900 control system family, the Giddings&Lewis 502-03518-03 analog output module is responsible for the core task of converting digital control signals into high-precision voltage analog signals. Its core value lies in providing stable driving signals for servo systems, process control links, and various industrial automation execution equipment. With multi-channel output design and excellent performance, it can easily adapt to industrial application scenarios with high requirements for signal accuracy and response speed, providing reliable support for the precise operation of automated production processes.
Technical Specifications
Channel configuration: Equipped with 8 independent analog output channels, it can simultaneously meet the signal driving requirements of multiple devices
Output voltage range: nominal ± 10V DC, actual working range can reach ± 11V DC, suitable for the voltage requirements of most industrial execution devices
Signal resolution: 16 bit high-precision resolution, corresponding to 65536 adjustment steps, ensuring the delicacy and accuracy of signal output
Output current capability: The maximum output current is ± 10mA, which can stably drive various load devices
Signal ｕｐｄａｔｅ efficiency: The output ｕｐｄａｔｅ interval is only 32 μ s, which quickly responds to control instructions and ensures the dynamic adjustment performance of the system
Output accuracy: Within the working range of ± 11V, the output accuracy is controlled within ± 5%, meeting the industrial grade accuracy standard
Reset mechanism: It has the functions of automatic power on reset and communication interruption reset. After reset, the output voltage stabilizes at 0V (error range ± 20mV) to avoid abnormal operation of the equipment
Signal stability: The output ripple is less than 10mV RMS (test frequency 30kHz), effectively reducing signal interference and ensuring stable operation of the equipment
Protection function: Built in short-circuit current limiting protection module, which can quickly limit the current when a short circuit occurs at the output terminal, protecting the module and backend equipment from damage
