ALCATEL LUCENT  3AL36154ABAA電路板模塊

1.產 品 資 料 介 紹：

中文資料：

ALCATEL-LUCENT 3AL36154ABAA 電路板模塊 是阿爾卡特朗訊用于電信核心設備中的一款專用功能模塊，廣泛應用于大型傳輸、交換或接入設備系統中。其主要任務是進行電信信號的處理、協議轉換、或系統內部數據的交互控制，屬于核心板卡結構的一部分。

一、基本信息

二、核心功能（根據常規系列用途推測）

1. 信號處理功能
   對來自不同模塊的信號進行轉換、整形或濾波處理，以保證系統正常識別。

2. 協議適配/轉換
   支持通信協議轉換（如ATM/IP、以太網等），提升系統靈活性與兼容性。

3. 系統控制支持
   協助主控板執行系統初始化、配置、狀態反饋等輔助控制功能。

4. 高速數據交互通道
   提供模塊間數據交換接口，構成背板通信總線中的一環。

5. 監測與自診斷
   板卡具備運行狀態檢測、故障自報功能，有助于系統快速排障。

英文資料：

The ALCATEL-LUCENT 3AL36154ABAA circuit board module is a specialized functional module used by Alcatel Lucent in telecommunications core equipment, widely used in large-scale transmission, switching, or access equipment systems. Its main task is to process telecommunications signals, convert protocols, or control the interaction of internal system data, which is part of the core board structure.

1、 Basic Information

Project Content

Product model 3AL36154ABAA

Product Name: PCB Module

Manufacturer ALCATEL-LUCENT

Function category: Control/Exchange/Processing module (depending on the system)

Applicable platform Alcatel core communication platform, DSLAM/OLT equipment, transmission system

2、 Core functions (inferred based on conventional series usage)

Signal processing function

Convert, shape, or filter signals from different modules to ensure normal system recognition.

Protocol adaptation/conversion

Support communication protocol conversion (such as ATM/IP, Ethernet, etc.) to enhance system flexibility and compatibility.

System control support

Assist the main control board in performing auxiliary control functions such as system initialization, configuration, and status feedback.

High speed data exchange channel

Provide data exchange interfaces between modules to form a part of the backplane communication bus.

Monitoring and self diagnosis

The board has the functions of running status detection and fault self reporting, which helps the system to quickly troubleshoot.

2.產      品      展      示
