ALCATEL LUCENT 3AL86603BFAG控制器模塊
1.產 品 資 料 介 紹：
中文資料：
ALCATEL-LUCENT 3AL86603BFAG 是一款用于電信級設備系統中的 控制器模塊（Controller Module），主要應用于 Alcatel-Lucent 的多業務接入平臺或傳輸設備中，承擔系統核心的管理、控制與通信調度任務。
一、產品基本信息
產品型號：3AL86603BFAG
產品類別：控制器模塊 / 主控板（Controller Module / CPU Board）
制造商：ALCATEL-LUCENT（現屬諾基亞）
所屬設備系列：通常應用于 Alcatel 1660 SM、1692 Metrospan、ISAM、7750 SR 等 中高端電信設備
二、主要功能特性
根據阿爾卡特朗訊控制類模塊的標準設計，該模塊可能具備以下主要功能：
1. 系統主控管理功能
作為整機的核心管理單元，負責系統初始化、配置加載、故障監控。
執行軟件和固件的啟動與運行控制。
2. 網絡協議處理
支持多種電信協議（如MPLS、IP、SONET/SDH、以太網、TDM等）。
處理轉發策略、控制面信令、路徑選擇等。
3. 遠程管理和接入
提供遠程配置、監控、維護支持（如通過CLI、SNMP、Telnet、Web等）。
支持熱插拔和自動配置重加載功能。
4. 故障診斷與系統監控
實時監控各個子系統的狀態、溫度、電壓、電流等。
出現故障時觸發告警并記錄日志便于排障。
5. 數據安全與加密支持（部分版本）
提供安全引導、訪問控制、鏈路加密等能力。
英文資料：
ALCATEL-LUCENT 3AL86603BFAG is a controller module used in telecom grade equipment systems, mainly applied in Alcatel Lucent's multi service access platforms or transmission devices, to undertake the management, control, and communication scheduling tasks of the system core.
1、 Basic Product Information
Product model: 3AL86603BFAG
Product Category: Controller Module/CPU Board
Manufacturer: ALCATEL-LUCENT (now part of Nokia)
Equipment series: Typically used in mid to high end telecommunications equipment such as Alcatel 1660 SM, 1692 Metrospan, ISAM, 7750 SR, etc
2、 Main functional features
According to the standard design of Alcatel Lucent control modules, this module may have the following main functions:
1. System main control management function
As the core management unit of the entire machine, responsible for system initialization, configuration loading, and fault monitoring.
Control the startup and operation of software and firmware.
2. Network protocol processing
Supports multiple telecommunications protocols such as MPLS, IP, SONET/SDH, Ethernet, TDM, etc.
Handling forwarding strategies, control plane signaling, path selection, etc.
3. Remote management and access
Provide remote configuration, monitoring, and maintenance support (such as through CLI, SNMP, Telnet, Web, etc.).
Support hot swapping and automatic configuration reload function.
4. Fault diagnosis and system monitoring
Real time monitoring of the status, temperature, voltage, current, etc. of each subsystem.
Trigger an alarm and record a log when a malfunction occurs for troubleshooting purposes.
5. Data security and encryption support (partial versions)
Provide security guidance, access control, link encryption, and other capabilities.
2.產 品 展 示
