ALCATEL LUCENT  3AL788568BDAD通信模塊

1.產 品 資 料 介 紹：

中文資料：

ALCATEL-LUCENT 3AL788568BDAD 通信模塊 - 技術規格與應用指南

1. 產品定位

3AL788568BDAD是諾基亞（原阿爾卡特-朗訊）推出的高性能多業務通信模塊，專為新一代融合網絡設計，主要應用于：

• 電信級設備的數據平面加速

• 多協議業務處理

• 高密度接口匯聚

2. 核心規格參數

3. 硬件架構亮點

3.1 處理系統

• 智能流量調度：

  • 基于P4可編程流水線

  • 硬件級微突發吸收（<10μs緩沖）

• 安全加速：

  • 內置IPsec加密引擎（支持國密SM4）

  • 線速MACsec處理

3.2 可靠性設計

• 雙星型電源輸入（-48V DC + 12V備份）

• 關鍵芯片溫度監控（±1℃精度）

• 前向糾錯（FEC）機制

英文資料：

ALCATEL-LUCENT 3AL788568BDAD Communication Module - Technical Specifications and Application Guide

1. Product positioning

3AL788568BDAD is a high-performance multi service communication module launched by Nokia (formerly Alcatel Lucent), designed specifically for the new generation of converged networks, mainly used for:

Data plane acceleration for telecom grade equipment

Multi protocol business processing

High density interface aggregation

2. Core specification parameters

Category Technical Indicators

Physical Characteristics - Dimensions: 290 × 220 × 35mm (compliant with ATCA standards)

-Weight: 1.8kg

Processing capability - equipped with FP5 network processor (16 cores @ 2.8GHz)

-Packet processing capability: 400Gbps line speed forwarding

Interface configuration -16 × 25G SFP28 or 4 × 100G QSFP28 (can be mixed)

-1 × 10G RJ45 management port

The protocol supports Ethernet/IPv6/MPLS/SRV6/VXLAN/Geneve

Environmental specifications - Operating temperature:- 5°C ~ +55°C

-Relative humidity: 5%~95% (non condensing)

3. Hardware architecture highlights

3.1 Processing System

Intelligent traffic scheduling:

Based on P4 programmable pipeline

Hardware level micro burst absorption (<10 μ s buffer)

Security acceleration:

Built in IPsec encryption engine (supporting SM4 encryption)

Line speed MACsec processing

3.2 Reliability Design

Double star power input (-48V DC+12V backup)

Key chip temperature monitoring (± 1 ℃ accuracy)

Forward Error Correction (FEC) mechanism
