Siemens 6SN1145-1BA01-0BA1數字控制模塊

1.產 品 資 料 介 紹：

中文資料：

Siemens 6SN1145-1BA01-0BA1 是 SIMODRIVE 611 系列中的一款 數字控制模塊（Digital Control Module），用于控制和調節 伺服驅動系統，特別是在數控機床（CNC）、機器人、自動化生產線等高精度設備中。此模塊通常用于管理和執行對伺服驅動、功率模塊和其他硬件設備的指令和信號處理。

主要技術參數

• 系列：SIMODRIVE 611
• 輸入電壓：三相 380-480V AC
• 輸出電壓：直流 600V DC（為驅動系統提供母線電壓）
• 輸入信號：支持 數字輸入/輸出（用于控制與監控伺服驅動系統）
• 通訊接口：
  • PROFIBUS 或 SERCOS（用于與其他控制系統和驅動模塊通信）
  • 高速、實時數據傳輸能力
• 兼容性：與 SIMODRIVE 611 系列伺服驅動模塊 完全兼容
• 控制方式：數字控制，適用于高精度的伺服驅動控制
• 內置功能：
  • 位置、速度、扭矩控制
  • 高速數據采集與實時監控

產品特點

• 高效數字控制
  • 提供精準的 位置、速度、加速度、扭矩控制，確保驅動系統的穩定性與精度
  • 實時控制與反饋機制，適合高要求工業應用
  • 適用于 閉環控制系統，提供更精細的性能調節
• 強大的通訊能力
  • 支持 PROFIBUS、SERCOS 通訊協議，能夠與不同的自動化控制系統進行連接
  • 適用于復雜的多軸控制和協同工作
• 模塊化設計
  • 與其他 SIMODRIVE 611 系列組件（如電源模塊、功率模塊等）無縫集成
  • 支持快速安裝和維護，減少生產線停機時間
• 高可靠性與穩定性
  • 提供 過載保護、短路保護 等功能，確保長期穩定運行
  • 適應工業環境中的 高溫、粉塵、震動 等挑戰
• 靈活的控制功能
  • 支持 多種伺服驅動控制方式，適應不同的工業需求

英文資料：

Siemens 6SN1145-1BA01-0BA1 is a digital control module in the SIMODRIVE 611 series, used to control and adjust servo drive systems, especially in high-precision equipment such as CNC machines, robots, and automated production lines. This module is typically used to manage and execute instructions and signal processing for servo drives, power modules, and other hardware devices.

Main technical parameters

Series: SIMODRIVE 611

Input voltage: three-phase 380-480V AC

Output voltage: 600V DC (providing bus voltage for the drive system)

Input signal: Supports digital input/output (used for controlling and monitoring servo drive systems)

Communication interface:

PROFIBUS or SERCOS (used for communication with other control systems and drive modules)

High speed and real-time data transmission capability

Compatibility: Fully compatible with SIMODRIVE 611 series servo drive modules

Control mode: digital control, suitable for high-precision servo drive control

Built in features:

Position, speed, torque control

High speed data acquisition and real-time monitoring

Product Features

Efficient digital control

Provide precise position, speed, acceleration, and torque control to ensure the stability and accuracy of the drive system

Real time control and feedback mechanism, suitable for high demand industrial applications

Suitable for closed-loop control systems, providing finer performance tuning

Powerful communication capability

Supports PROFIBUS and SERCOS communication protocols, capable of connecting with different automation control systems

Suitable for complex multi axis control and collaborative work

Modular design

Seamless integration with other SIMODRIVE 611 series components such as power modules, power modules, etc

Support fast installation and maintenance, reducing production line downtime

High reliability and stability

Provide overload protection, short circuit protection and other functions to ensure long-term stable operation

Adapt to challenges such as high temperature, dust, and vibration in industrial environments

Flexible control function

Support multiple servo drive control methods to adapt to different industrial needs

2.產      品      展      示
