INDRAMAT  TDM3.2-20-300-W0 伺服控制器

1.產 品 資 料 介 紹：

中文資料：

INDRAMAT TDM3.2-20-300-W0 伺服控制器 是 Bosch Rexroth 旗下 INDRAMAT 系列的一款高性能伺服驅動器，專為工業自動化設計，廣泛應用于機床、包裝機械、印刷機械以及其他需要高精度運動控制的場景。

產品特點：

1. 高精度控制：

   • 支持快速響應和精確位置控制，適用于高動態要求的應用場景。
   • 提供高質量的轉矩控制和速度調節。

2. 模塊化設計：

   • 緊湊的結構便于安裝在控制柜中，節省空間。
   • 可與其他 INDRAMAT 系列設備集成，支持靈活的系統設計。

3. 兼容性強：

   • 適用于多個伺服電機型號，如 2AD 和 1MB 系列電機。
   • 支持與主控制系統的無縫連接。

4. 高可靠性：

   • 工業級設計，適合長時間運行，耐用性高。
   • 具備多種保護功能，如過電流、過溫、過壓和短路保護。

技術參數：

• 型號：TDM3.2-20-300-W0
• 輸入電壓：三相 300V
• 功率范圍：適合驅動 20A 電機電流的伺服電機
• 冷卻方式：自然冷卻
• 通信接口：支持與工業控制系統通信（如 PLC）
• 保護等級：IP20（適合室內工業環境）
• 工作溫度范圍：0°C 至 +45°C
• 存儲溫度范圍：-25°C 至 +85°C
• 安裝位置：垂直安裝，需注意通風和散熱條件

英文資料：

The INDRAMAT TDM3.2-20-300-W0 servo controller is a high-performance servo drive from Bosch Rexroth's INDRAMAT series, designed specifically for industrial automation and widely used in machine tools, packaging machinery, printing machinery, and other scenarios that require high-precision motion control.

Product features:

High precision control:

Supports fast response and precise position control, suitable for application scenarios with high dynamic requirements.

Provide high-quality torque control and speed regulation.

Modular design:

The compact structure is easy to install in the control cabinet, saving space.

It can be integrated with other INDRAMAT series devices and supports flexible system design.

Strong compatibility:

Suitable for multiple servo motor models, such as 2AD and 1MB series motors.

Support seamless connection with the main control system.

High reliability:

Industrial grade design, suitable for long-term operation, high durability.

It has multiple protection functions, such as overcurrent, overtemperature, overvoltage, and short-circuit protection.

Technical parameters:

model: TDM3.2-20-300-W0

Input voltage: Three phase 300V

Power range: Suitable for driving servo motors with a current of 20A

Cooling method: natural cooling

Communication interface: supports communication with industrial control systems (such as PLC)

Protection level: IP20 (suitable for indoor industrial environments)

Working temperature range: 0 ° C to+45 ° C

Storage temperature range:- 25 ° C to+85 ° C

Installation position: Vertical installation, attention should be paid to ventilation and heat dissipation conditions

2.產      品      展      示
