Ulstein Tenfjord 5801-SD100C 電磁閥驅動轉向裝置
1.產 品 資 料 介 紹：
中文資料：
Ulstein Tenfjord 5801-SD100C 電磁閥驅動轉向裝置 是一款高性能的船舶轉向系統組件，專為滿足海洋船舶在各種操作條件下的精確和可靠轉向需求而設計。以下是該設備的詳細信息：
產品概述
功能描述：
- 作為電液轉向系統的重要組成部分，通過控制電磁閥驅動液壓動力裝置，實現船舶舵機的精準操作。
- 提供高靈敏度的響應能力，適合大型商船、游輪、海工船和其他船舶使用。
設計特點：
- 電磁閥驅動： 利用電信號控制液壓流量和壓力，確保轉向動作的快速響應和高精度。
- 模塊化結構： 易于安裝和維護，適用于復雜的船舶工程設計。
- 耐久性： 采用高強度材料和防腐蝕涂層，適應惡劣海洋環境。
技術參數
| 參數 | 規格說明 |
|---|---|
| 型號 | 5801-SD100C |
| 工作電壓 | 通常為 24V DC（具體型號可能支持不同電壓） |
| 驅動方式 | 電磁閥驅動液壓控制 |
| 流量范圍 | 具體數值取決于系統設計 |
| 工作溫度范圍 | -20°C 至 +70°C |
| 壓力范圍 | 高壓液壓系統，通常高達 250 bar 或更高 |
| 響應時間 | 快速響應，適合動態轉向操作 |
| 控制信號接口 | 數字或模擬輸入，支持與船舶控制系統集成 |
| 材料 | 耐腐蝕鋼材和復合材料 |
| 防護等級 | IP66 或更高（具體型號確認） |
英文資料：
Ulstein Tenfjord 5801-SD100C electromagnetic valve driven steering device is a high-performance ship steering system component designed to meet the precise and reliable steering needs of marine vessels under various operating conditions. The following is the detailed information of the device:
Product Overview
Function description:
As an important component of the electro-hydraulic steering system, the precise operation of the ship's servo is achieved by controlling the solenoid valve to drive the hydraulic power device.
It provides high sensitivity response capability and is suitable for large merchant ships, cruise ships, offshore factory ship and other ships.
Design features:
Electromagnetic valve drive: using electrical signals to control hydraulic flow and pressure, ensuring fast response and high precision of steering actions.
Modular structure: easy to install and maintain, suitable for complex ship engineering design.
Durability: Made of high-strength materials and corrosion-resistant coatings, suitable for harsh marine environments.
technical parameter
Parameter specification description
Model 5801-SD100C
The working voltage is usually 24V DC (specific models may support different voltages)
Driving method: Electromagnetic valve drives hydraulic control
The specific value of the flow range depends on the system design
Working temperature range -20 ° C to+70 ° C
Pressure range for high-pressure hydraulic systems, typically up to 250 bar or higher
Fast response time, suitable for dynamic steering operations
Control signal interface digital or analog input, supporting integration with ship control system
Corrosion resistant steel and composite materials
Protection level IP66 or higher (specific model confirmed)
2.產 品 展 示
