GE IS420UCSBH1A 控制器模塊

1.產 品 資 料 介 紹：

中文資料：

GE 的 IS420UCSBH1A 是 Mark VIe 控制系統中的 UCSB 控制器模塊，專為執行特定應用的控制邏輯而設計。與傳統控制器不同，UCSB 控制器不直接托管應用 I/O，而是通過 IONet 網絡與 I/O 模塊通信，確保即使在控制器維護或維修期間，應用輸入數據也不會丟失。

主要特點：

• 獨立計算能力：作為獨立的計算機，UCSB 控制器預裝特定應用軟件，能夠運行梯級或塊邏輯。

• 實時同步：采用 IEEE 1588 協議，通過 R、S 和 T IONet 將 I/O 組件和控制器的時鐘同步到 100 微秒以內，確保系統的高精度同步。

• 模塊化設計：控制器采用風冷設計，無需板載風扇或電池，內置電源，簡化了系統架構。

技術規格：

• 處理器：可能采用 Freescale MPC7534 或 Intel EP80579。

• 內存：256 MB DDR2 SDRAM，帶糾錯碼 (ECC)；2 GB NAND 閃存。

• 網絡接口：支持 IONet 和以太網連接。

• 電源要求：18-36V DC。

• 工作溫度范圍：-40°C 至 +85°C。

• 尺寸：150mm x 100mm x 50mm。

• 重量：約 500g。

應用領域：

IS420UCSBH1A 控制器模塊廣泛應用于工業自動化、過程控制、數據采集與監測、能源管理等領域，特別適用于需要高可靠性和精確控制的場景

英文資料：

GE's IS420UCSBH1A is the UCSB controller module in the Mark VIe control system, designed specifically for executing control logic for specific applications. Unlike traditional controllers, UCSB controllers do not directly host application I/O, but communicate with I/O modules through the IONet network to ensure that application input data is not lost even during controller maintenance or repair.

Main features:

Independent computing capability: As an independent computer, the UCSB controller comes pre installed with specific application software that can run cascade or block logic.

Real time synchronization: Using the IEEE 1588 protocol, the clocks of I/O components and controllers are synchronized to within 100 microseconds through R, S, and T IONet, ensuring high-precision synchronization of the system.

Modular design: The controller adopts an air-cooled design, eliminating the need for onboard fans or batteries, and has a built-in power supply, simplifying the system architecture.

Technical specifications:

Processor: Freescale MPC7534 or Intel EP80579 may be used.

Memory: 256 MB DDR2 SDRAM with error correction code (ECC); 2 GB NAND flash memory.

Network interface: Supports IONet and Ethernet connections.

Power requirement: 18-36V DC.

Working temperature range:- 40 ° C to+85 ° C.

Size: 150mm x 100mm x 50mm.

Weight: Approximately 500g.

Application areas:

The IS420UCSBH1A controller module is widely used in industrial automation, process control, data acquisition and monitoring, energy management and other fields, especially suitable for scenarios that require high reliability and precise control

2.產      品      展      示
