Multilin 1228-0003-D6輸入輸出系統板  是 GE（現為 GE 智能電網）MULTILIN 系列中的一個模塊化組件。

Multilin 1228-0003-D6輸入輸出系統板  詳情介紹：

MULTILIN 1228-0003-D6 輸入輸出系統板是 GE（現為 GE 智能電網）MULTILIN 系列中的一個模塊化組件。該系統板用于擴展 MULTILIN 保護繼電器的輸入和輸出功能，提供靈活的接口用于監控和控制電力系統中的設備。

主要特點和功能

1. 輸入功能

• 數字輸入：支持多個數字輸入，用于接收來自各種設備和傳感器的狀態信號。適用于觸發報警、記錄事件或控制動作。
• 模擬輸入：部分型號支持模擬輸入，可以監測電流、電壓等模擬信號，并將其轉換為數字?jǐn)?shù)據進行處理。

2. 輸出功能

• 數字輸出：提供多個數字輸出通道，用于驅動外部設備如開關、指示燈或報警器。這些輸出可以配置為執行各種控制操作。
• 模擬輸出：某些型號可能提供模擬輸出，用于輸出電流或電壓信號，方便與其他系統進行數據交換或控制。

3. 通信接口

• 支持多種通信協議：兼容 Modbus、DNP3、IEC 61850 等常見通信協議，方便與其他設備和系統的集成。
• 網絡接口：提供網絡接口，支持遠程監控、數據交換和系統管理。

4. 功能擴展

• 模塊化設計：具有模塊化設計，可以與其他 MULTILIN 模塊組合，靈活配置系統功能，以適應不同的應用需求。
• 增強功能：通過添加輸入輸出系統板，可以擴展保護繼電器的功能，包括更多的控制和監測選項。

5. 用戶界面

• 圖形化顯示：配備直觀的用戶界面，便于配置、監控和查看輸入輸出系統板的狀態。
• 遠程管理：支持遠程訪問和操作，允許從不同地點進行系統管理和維護。

6. 可靠性和耐用性

• 工業級設計：設計用于適應各種工業環境，具備高耐用性和穩定性。
• 自診斷功能：具備自診斷能力，能夠快速檢測和報告系統中的問題，確保可靠運行。

Multilin 1228-0003-D6輸入輸出系統板  實物圖片：

english introduction:

Multilin MIVII1000E00HI is a voltage protection relay in the MULTILIN series of GE (now GE Smart Grid). This relay is designed to monitor and protect the voltage in the power system, ensuring the stability and safety of the system under abnormal voltage conditions.

Main features and functions

Voltage protection function

Undervoltage protection: When the detection system voltage is below the set threshold, provide undervoltage protection to prevent the equipment from operating under low voltage conditions.

Overvoltage protection: When the monitoring voltage exceeds the set threshold, provide overvoltage protection to avoid damage to the equipment caused by high voltage.

Voltage recovery function: After the voltage returns to the normal range, the equipment will automatically resume operation.

Advanced monitoring

Real time voltage measurement: Real time monitoring of voltage in the power system, providing accurate data for analysis and decision-making.

Fault record: Record data on abnormal voltage and protective actions to assist in fault analysis and system maintenance.

Wave monitoring: detecting voltage fluctuations and instantaneous changes to ensure system stability.

Protection and control

Automatic switching: Automatically cuts off or switches power supply when abnormal voltage is detected, protecting equipment and systems.

Alarm function: Provides alarm output to notify the operator in case of abnormal voltage, facilitating timely action.

Communication and Integration

Supports multiple protocols: compatible with communication protocols such as Modbus, DNP3, IEC 61850, etc., facilitating integration with other systems and devices.

Network Interface: Provides network interfaces that support remote monitoring, data exchange, and system management.

user interface

Graphic display: equipped with an intuitive graphical user interface for easy configuration, monitoring, and viewing of voltage protection status.

Remote access: Supports remote access and management, allowing system monitoring and operations from different locations.

Reliability and durability

Durable design: Designed for various industrial environments, it has high durability and stability.

Self diagnostic function: With self diagnostic capability, it can quickly detect and report problems in the system, ensuring the reliable operation of the equipment.
