MULTILIN 369-HI-0-M-0-E電機管理繼電器 是 GE（現為GE智能電網）制造的一款電機管理繼電器，屬于 MULTILIN 369 系列。

MULTILIN 369-HI-0-M-0-E電機管理繼電器 詳情介紹：

MULTILIN 369-HI-0-M-0-E 是 GE（現為GE智能電網）制造的一款電機管理繼電器，屬于 MULTILIN 369 系列。該系列繼電器專為電動機保護和控制設計，提供了多種功能來確保電動機的安全運行和可靠性。

主要特點和功能

1. 電機保護

• 過載保護：提供對電動機的過載保護，防止由于長期過載而導致的設備損壞。
• 堵轉保護：監測電動機的啟動過程，防止因堵轉導致的過熱和損壞。
• 過熱保護：通過溫度傳感器監測電動機的運行溫度，防止因過熱而引發故障。
• 相序監測：檢測電動機的相序，以防止因相序錯誤導致的電動機損壞。

2. 監測與診斷

• 實時數據監測：提供實時的電動機運行數據，包括電流、電壓、功率等。
• 故障記錄：記錄故障事件和數據，以便于故障分析和維護。
• 運行狀態監測：監測電動機的運行狀態，包括啟動次數和運行時間。

3. 控制功能

• 啟動和停止控制：支持電動機的遠程啟動和停止控制。
• 自動重啟：在發生暫時性故障后，可以自動重新啟動電動機，減少停機時間。
• 保護設置：允許用戶根據電動機的特性進行保護設置和調整。

4. 通信與集成

• 支持多種通信協議：如Modbus、DNP3、IEC 61850等，便于與其他設備和系統集成。
• 網絡接口：提供網絡接口，支持遠程監控和管理，提升操作靈活性。

5. 用戶界面

• 圖形化顯示：配備直觀的圖形用戶界面，便于配置和監控電動機狀態。
• 遠程管理：支持遠程訪問和控制，允許從不同地點管理和操作設備。

6. 可靠性和耐用性

• 堅固設計：設計用于適應各種工業環境，具有高耐用性和穩定性。
• 自診斷功能：具備自診斷能力，可以快速檢測和報告系統中的問題。

MULTILIN 369-HI-0-M-0-E電機管理繼電器 實物圖片：

english introduction:

MULTILIN 369-HI-0-M-0-E is a motor management relay manufactured by GE (now GE Smart Grid) and belongs to the MULTILIN 369 series. This series of relays is designed specifically for motor protection and control, providing multiple functions to ensure the safe operation and reliability of the motor.

Main features and functions

Motor protection

Overload protection: Provides overload protection for electric motors to prevent equipment damage caused by long-term overload.

Lock rotor protection: Monitor the starting process of the motor to prevent overheating and damage caused by lock rotor.

Overheating protection: Monitor the operating temperature of the motor through a temperature sensor to prevent malfunctions caused by overheating.

Phase sequence monitoring: Detecting the phase sequence of the motor to prevent damage caused by phase sequence errors.

Monitoring and Diagnosis

Real time data monitoring: Provide real-time motor operation data, including current, voltage, power, etc.

Fault record: Record fault events and data for the purpose of fault analysis and maintenance.

Operation status monitoring: Monitor the operation status of the motor, including the number of starts and running time.

control function

Start and stop control: Supports remote start and stop control of electric motors.

Automatic restart: In the event of a temporary malfunction, the motor can be automatically restarted to reduce downtime.

Protection settings: Allow users to set and adjust protection based on the characteristics of the motor.

Communication and Integration

Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., making it easy to integrate with other devices and systems.

Network interface: Provides network interfaces, supports remote monitoring and management, and enhances operational flexibility.

user interface

Graphic display: equipped with an intuitive graphical user interface for easy configuration and monitoring of motor status.

Remote management: supports remote access and control, allowing devices to be managed and operated from different locations.

Reliability and durability

Durable design: Designed to adapt to various industrial environments, with high durability and stability.

Self diagnostic function: With self diagnostic capability, it can quickly detect and report problems in the system.
