ABB PFSA140 3BSE006503R1 供應單元模塊
1.產 品 資 料 介 紹：
中文資料：
一、產品簡介
ABB PFSA140 3BSE006503R1 是 ABB 公司為其 Freelance DCS（AC 800F 系統） 設計的一款 直流電源模塊，用于為控制器、通訊模塊、I/O 模塊等提供穩定的電源支持。它是該系統中不可或缺的基礎供電單元。
二、主要技術參數
| 項目 | 參數說明 |
|---|---|
| 產品型號 | PFSA140 |
| 訂貨號 | 3BSE006503R1 |
| 輸入電壓范圍 | 18 ~ 32 VDC（典型 24 VDC） |
| 輸出電壓 | 穩定的 24 VDC，供內部模塊使用 |
| 輸出功率 | 約 30 W（根據系統負載而定） |
| 工作溫度 | -20°C 至 +60°C |
| 安裝方式 | DIN 導軌安裝或模塊式插入系統背板 |
| 狀態顯示 | LED 狀態指示燈（供電狀態、故障等） |
| 電氣保護 | 具備過壓、過流、短路保護 |
| 冗余支持 | 支持雙模塊冗余熱備份運行方式 |
| 使用壽命 | 工業級設計，滿足長期穩定運行需求 |
三、功能與特點
高可靠性供電：保障 DCS 控制系統連續運行，防止因電壓波動導致的系統異常。
全面保護機制：具備過載、過壓和短路保護，提高系統安全性。
模塊化結構：便于集成于 ABB Freelance 控制系統中，快速安裝與更換。
狀態監測清晰：LED 指示燈實時反映模塊運行狀態，便于現場診斷。
支持冗余電源模式：可配合第二個 PFSA140 實現無縫備份，提高系統可靠性。
英文資料：
Brief introduction
ABB PFSA140 3BSE006503R1 is a DC power module designed by ABB for its Freelance DCS (AC 800F system), used to provide stable power support for controllers, communication modules, I/O modules, etc. It is an indispensable basic power supply unit in the system.
2、 Main technical parameters
Project parameter description
Product model PFSA140
Order number 3BSE006503R1
Input voltage range 18~32 VDC (typical 24 VDC)
Stable output voltage of 24 VDC for internal module use
Output power is approximately 30 W (depending on system load)
Working temperature -20 ° C to+60 ° C
Installation method: DIN rail installation or modular insertion system backplane
Status display LED status indicator light (power supply status, fault, etc.)
Electrical protection has overvoltage, overcurrent, and short-circuit protection
Redundancy support supports dual module redundant heat backup operation mode
Industrial grade design with a service life that meets long-term stable operation requirements
3、 Function and Features
High reliability power supply: ensuring the continuous operation of DCS control system and preventing system abnormalities caused by voltage fluctuations.
Comprehensive protection mechanism: equipped with overload, overvoltage, and short-circuit protection to improve system safety.
Modular structure: easy to integrate into ABB Freelance control systems for quick installation and replacement.
Clear status monitoring: LED indicator lights reflect the real-time operation status of the module, facilitating on-site diagnosis.
Support redundant power mode: can be seamlessly backed up with a second PFSA140 to improve system reliability.
2.產 品 展 示
