ABB SYCHROTACT 5  3BHB006716R0277 自動同步器

1.產 品 資 料 介 紹：

中文資料：

SYCHROTACT 5 3BHB006716R0277 是 ABB 生產的一款 自動同步器，用于同步發電機與電網或母線，確保安全、精確的并網操作。它在電力系統中扮演關鍵角色，特別適用于發電廠、工業電網和分布式能源系統。

1. 產品概述

• 產品型號：SYCHROTACT 5 3BHB006716R0277
• 制造商：ABB
• 設備類型：自動同步器（Automatic Synchronizer）
• 應用場景：同步發電機與電網，確保安全、精準并網

2. 主要特點

• 高精度同步：

  • 實時測量 電壓、頻率、相角，確保并網精度
  • 具備可調同步參數，提高系統適應性

• 自動化控制：

  • 可自動執行并網過程，減少人為干預，提高安全性
  • 具備手動/自動兩種工作模式

• 兼容性強：

  • 適用于不同類型的發電機（同步發電機、異步發電機等）
  • 可兼容多種電力系統架構

• 內置保護功能：

  • 具備過壓、欠壓、過頻、欠頻、相序錯誤等多種保護功能
  • 避免誤操作導致的設備損壞

• 通信與接口：

  • 支持 Modbus、IEC 61850 等工業通信協議（具體型號支持情況需確認）
  • 具備 RS-485、以太網 等數據接口，便于遠程監控

英文資料：

SYCHROTACT 5 3BHB006716R0277 is an automatic synchronizer produced by ABB, used to synchronize generators with the grid or busbar, ensuring safe and accurate grid connection operations. It plays a crucial role in the power system, particularly suitable for power plants, industrial grids, and distributed energy systems.

1. Product Overview

Product model: SYCHROTACT 5 3BHB006716R0277

manufacturer: ABB

Equipment type: Automatic Synchronizer

Application scenario: Synchronize generators with the power grid to ensure safe and accurate grid connection

2. Main features

High precision synchronization:

Real time measurement of voltage, frequency, and phase angle to ensure grid accuracy

Equipped with adjustable synchronization parameters to improve system adaptability

Automated control:

Automatically execute the grid connection process, reduce human intervention, and improve safety

Equipped with manual/automatic working modes

Strong compatibility:

Suitable for different types of generators (synchronous generators, asynchronous generators, etc.)

Compatible with multiple power system architectures

Built in protection function:

It has multiple protection functions such as overvoltage, undervoltage, overclocking, underfrequency, and phase sequence error

Prevent equipment damage caused by misoperation

Communication and Interface:

Supports industrial communication protocols such as Modbus and IEC 61850 (specific model support needs to be confirmed)

Equipped with RS-485, Ethernet and other data interfaces for remote monitoring

2.產      品      展      示
