TEWS  TPMC871-10 接口模塊   是一款高性能的I/O模塊，專為在崎嶇和惡劣的環境中使用而設計。它基于Industry Pack（IP）夾層標準，適用于VMEbus和CompactPCI單板計算機。

TEWS  TPMC871-10 接口模塊  詳情介紹：

1. TEWS TPMC871-10接口模塊是一款高性能的I/O模塊，專為在崎嶇和惡劣的環境中使用而設計。它基于Industry Pack（IP）夾層標準，適用于VMEbus和CompactPCI單板計算機。

2. 該模塊具有以下特點：

3. 輸入/輸出通道：TPMC871-10配備了四個模擬輸入通道，這些通道可配置為接收電壓或電流輸入。此外，它還具有四個模擬輸出通道，這些通道可設置為電壓或電流輸出。同時，該模塊還提供了八個數字輸入通道和八個數字輸出通道，以滿足各種數字信號的處理需求。
4. 工作溫度范圍：該模塊設計用于在-40°C至+85°C的溫度范圍內工作，這使其能夠適應各種惡劣的工業環境。
5. PC卡插槽：TPMC871-10是一個標準的單寬度32位PMC模塊，具有一個接口，用于16位PC卡或32位Cardbus卡。這個插槽支持I類和II類內存以及I/O卡，為系統提供了額外的擴展能力和靈活性。
6. 電源管理：由于電源管理單元的短路和熱保護功能，該模塊不需要外部保險絲。此外，它還支持多達五個存儲器窗口和多達兩個I/O窗口的訪問，以實現對PC卡資源的有效管理。

7. 在工業自動化系統中，TPMC871-10接口模塊扮演著關鍵的角色。它負責處理系統內外的數字或模擬信號，以實現與外部設備（如傳感器、執行器、開關等）的通信和控制。這些模塊在控制系統中發揮著重要作用，幫助實現對生產過程的監測、調節和控制。

8. 總之，TEWS TPMC871-10接口模塊是一款高性能、多功能的I/O模塊，適用于各種惡劣環境和工業自動化應用。它的豐富功能和強大的性能使其成為工業自動化系統中的關鍵組件之一。

TEWS  TPMC871-10 接口模塊   實物圖片：

TEWS  TPMC871-10 接口模塊  實物視頻

TEWS TPMC871-10 Interface Module Details Introduction:

The TEWS TPMC871-10 interface module is a high-performance I/O module designed specifically for use in rugged and harsh environments. It is based on the Industry Pack (IP) mezzanine standard and is suitable for VMEbus and CompactPCI single board computers.

This module has the following characteristics:

Input/Output Channels: TPMC871-10 is equipped with four analog input channels, which can be configured to receive voltage or current inputs. In addition, it also has four analog output channels, which can be set for voltage or current output. At the same time, the module also provides eight digital input channels and eight digital output channels to meet various digital signal processing needs.

Working temperature range: This module is designed to operate within the temperature range of -40 ° C to+85 ° C, which enables it to adapt to various harsh industrial environments.

PC card slot: TPMC871-10 is a standard single width 32-bit PMC module with an interface for 16 bit PC cards or 32-bit Cardbus cards. This slot supports Class I and Class II memory as well as I/O cards, providing additional scalability and flexibility for the system.

Power management: Due to the short-circuit and thermal protection functions of the power management unit, this module does not require external fuses. In addition, it also supports access to up to five memory windows and up to two I/O windows to achieve effective management of PC card resources.

In industrial automation systems, the TPMC871-10 interface module plays a crucial role. It is responsible for processing digital or analog signals both inside and outside the system to achieve communication and control with external devices such as sensors, actuators, switches, etc. These modules play an important role in the control system, helping to monitor, regulate, and control the production process.

In summary, the TEWS TPMC871-10 interface module is a high-performance and multifunctional I/O module suitable for various harsh environments and industrial automation applications. Its rich functionality and powerful performance make it one of the key components in industrial automation systems.
