GIDDINGS & LEWIS DSM175伺服驅動器

1.產 品 資 料 介 紹：

GIDDINGS & LEWIS DSM175 伺服驅動器產品詳解

一、產品概述：工業自動化的核心驅動單元

二、技術參數：適配多樣化工業場景

核心性能參數

• 額定電流：支持大功率伺服電機驅動，輸出電流范圍寬泛，能夠適配不同功率等級的電機，滿足從中小功率到較大功率設備的驅動需求。
• 電源輸入：采用三相 AC 工業電源，常見電壓范圍為 380V~480V，符合工業用電標準，便于接入各類工業供電系統。
• 控制模式：具備位置控制、速度控制、扭矩控制三種核心模式，可根據實際應用場景靈活切換。例如，在精密定位場景中選用位置控制模式，在恒速運行場景中采用速度控制模式，在負載恒定的場合則可使用扭矩控制模式。
• 反饋類型：兼容編碼器、解析器等多種閉環反饋裝置，通過實時接收反饋信號，實現對電機運行狀態的精準監控與調節，保證控制精度。

保護與接口特性

• 保護功能：內置全面的保護機制，包括過壓、欠壓保護（防止電源電壓異常損壞設備）、過流保護（避免電機或驅動器因電流過大燒毀）、過熱保護（當設備溫度過高時自動停機）、短路保護（應對電路短路故障）及反饋異常保護（確保反饋信號異常時系統安全），大幅提升設備運行的安全性與可靠性。
• 接口：配備多種通訊總線接口，可便捷地與上位機、PLC 等控制系統連接，實現數據的實時交互與指令傳輸，融入復雜的工業自動化網絡。

英文資料：

GIDINGS&LEWIS DSM175 servo drive product detailed explanation

1、 Product Overview: The Core Driver Unit of Industrial Automation

GIDINGS&LEWIS DSM175 servo drive, as a high-performance drive unit designed specifically for industrial automation and motion control systems, is a key bridge connecting control systems and servo motors. It works in conjunction with feedback devices such as servo motors, encoders, and parsers to build a complete closed-loop control system, accurately regulating the three core parameters of speed, position, and torque.

As an important member of the G&L brand DSM series, this driver has become a core driver product in high-end CNC machine tools and automation equipment due to its excellent performance. The original intention of its design is to meet the stringent requirements of high dynamic response and high-precision machining, providing a solid guarantee for precision motion control in industrial production.

2、 Technical parameters: Suitable for diverse industrial scenarios

Core performance parameters

Rated current: Supports high-power servo motor drive, with a wide range of output currents, able to adapt to motors of different power levels, and meet the driving needs of devices ranging from medium to high power.

Power input: Adopting three-phase AC industrial power supply, the common voltage range is 380V~480V, which meets industrial power standards and is easy to connect to various industrial power supply systems.

Control mode: It has three core modes: position control, speed control, and torque control, which can be flexibly switched according to actual application scenarios. For example, in precision positioning scenarios, position control mode is used, in constant speed operation scenarios, speed control mode is used, and in situations where the load is constant, torque control mode can be used.

Feedback type: Compatible with various closed-loop feedback devices such as encoders and parsers, it achieves precise monitoring and adjustment of motor operation status by receiving feedback signals in real time, ensuring control accuracy.

Protection and Interface Characteristics

Protection function: Built in comprehensive protection mechanisms, including overvoltage and undervoltage protection (to prevent abnormal power supply voltage from damaging equipment), overcurrent protection (to prevent motors or drivers from burning out due to excessive current), overheating protection (to automatically shut down when the equipment temperature is too high), short circuit protection (to deal with circuit short circuit faults), and feedback abnormality protection (to ensure system safety in case of abnormal feedback signals), greatly improving the safety and reliability of equipment operation.

Interface: Equipped with multiple communication bus interfaces, it can easily connect with control systems such as upper computer and PLC, achieve real-time data interaction and instruction transmission, and integrate into complex industrial automation networks.

2.產      品      展      示
