SR745-W2-P1-G1-HI-A-L-R-E變壓器管理繼電器 是一款由 GE（通用電氣）公司生產的變壓器管理繼電器。

SR745-W2-P1-G1-HI-A-L-R-E變壓器管理繼電器  詳情介紹：

GE SR745-W2-P1-G1-HI-A-L-R-E 是一款由 GE（通用電氣）公司生產的變壓器管理繼電器。它設計用于變電站和電力系統中的變壓器保護與監控，提供多種保護功能，確保變壓器在各種工作條件下的安全運行。這款繼電器適合用于要求嚴格的電力系統環境中，如發電廠、變電站和工業設施。

主要功能和特點：

1. 變壓器保護功能：

• 差動保護：監測變壓器內部的電流差異，以檢測可能的故障，如短路或繞組故障。差動保護可以有效識別并隔離故障區域，防止故障擴大。
• 過電流保護：提供過電流保護功能，防止由于負載過大或短路引起的變壓器損壞。
• 過電壓/欠電壓保護：監控變壓器的電壓水平，防止由于電壓異常對變壓器造成的損害。
• 溫度保護：通過溫度傳感器監測變壓器的溫度，防止因過熱導致的設備損壞。

2. 監控和控制功能：

• 實時監控：提供對變壓器運行狀態的實時監控，包括電流、電壓、溫度等參數，確保變壓器在安全范圍內運行。
• 遠程控制：支持遠程通信和控制功能，可以通過網絡或通信接口對保護繼電器進行遠程操作和監控。

3. 通信接口：

• 多種通信協議：支持多種通信協議，如 Modbus、DNP3、IEC 61850 等，便于與其他系統集成，實現數據的遠程傳輸和系統監控。
• 數據傳輸：能夠?qū)⒈O(jiān)控?cái)?shù)據和狀態信息傳輸至中央控制系統或遠程服務器，便于集中管理和分析。

4. 保護和報警功能：

• 報警機制：提供多種報警方式，如聲光報警、繼電器輸出等，當檢測到異常情況時，能夠及時提醒操作人員。
• 保護動作：在發生嚴重故障時，模塊能夠自動采取保護措施，如斷電、隔離故障區域等，保護變壓器和相關設備。

5. 配置和調試：

• 易于配置：支持通過配置軟件進行參數設置，調整保護功能、報警閾值等，以滿足不同的應用需求。
• 用戶界面：提供友好的用戶界面，方便用戶進行設置、操作和故障診斷。

6. 高可靠性和穩定性：

• 工業級設計：符合工業標準，具有高抗干擾能力和高可靠性，能夠在惡劣的工業環境中穩定運行。
• 冗余設計：具備冗余機制，在關鍵部件發生故障時，系統能夠繼續運行，保障保護功能的持續性。

SR745-W2-P1-G1-HI-A-L-R-E變壓器管理繼電器 實物圖片：

english introduction:

GE SR745-W2-P1-G1-HI-A-L-R-E is a transformer management relay produced by GE (General Electric). It is designed for transformer protection and monitoring in substations and power systems, providing multiple protection functions to ensure the safe operation of transformers under various working conditions. This relay is suitable for use in demanding power system environments such as power plants, substations, and industrial facilities.

Main functions and features:

Transformer protection function:

Differential protection: Monitor the current difference inside the transformer to detect possible faults, such as short circuits or winding faults. Differential protection can effectively identify and isolate fault areas, preventing the expansion of faults.

Overcurrent protection: Provides overcurrent protection function to prevent transformer damage caused by excessive load or short circuit.

Overvoltage/undervoltage protection: Monitor the voltage level of the transformer to prevent damage caused by abnormal voltage to the transformer.

Temperature protection: Monitor the temperature of the transformer through a temperature sensor to prevent equipment damage caused by overheating.

Monitoring and control functions:

Real time monitoring: Provides real-time monitoring of the operating status of transformers, including parameters such as current, voltage, temperature, etc., to ensure that transformers operate within a safe range.

Remote control: Supports remote communication and control functions, and can remotely operate and monitor protective relays through networks or communication interfaces.

Communication interface:

Multiple communication protocols: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., making it easy to integrate with other systems and achieve remote data transmission and system monitoring.

Data transmission: capable of transmitting monitoring data and status information to a central control system or remote server for centralized management and analysis.

Protection and alarm functions:

Alarm mechanism: Provides multiple alarm methods, such as sound and light alarms, relay outputs, etc., to promptly alert operators when abnormal situations are detected.

Protection action: In the event of a serious fault, the module can automatically take protective measures, such as power outage, isolation of the fault area, etc., to protect the transformer and related equipment.

Configuration and debugging:

Easy to configure: Supports parameter settings, adjustment of protection functions, alarm thresholds, etc. through configuration software to meet different application requirements.

User Interface: Provides a user-friendly interface that facilitates users in setting up, operating, and diagnosing faults.

High reliability and stability:

Industrial grade design: meets industrial standards, has high anti-interference ability and high reliability, and can operate stably in harsh industrial environments.

Redundancy design: Equipped with redundancy mechanisms, the system can continue to operate in the event of critical component failures, ensuring the continuity of protection functions.
