MULTILIN 345-E-P5-G5-H變壓器保護系統 是 GE（現為GE智能電網）制造的變壓器保護系統的一部分，專為變壓器保護和監控設計。

MULTILIN 345-E-P5-G5-H變壓器保護系統 詳情介紹：

MULTILIN 345-E-P5-G5-H 是 GE（現為GE智能電網）制造的變壓器保護系統的一部分，專為變壓器保護和監控設計。這個系統包括了多個保護功能，確保變壓器在各種運行條件下的安全和穩定。

主要特點和功能

1. 綜合變壓器保護

• 過電流保護：提供針對高電流的保護，以防止因過載或短路引發的變壓器損壞。
• 差動保護：實現對變壓器內部故障的保護，通過比較輸入和輸出電流，檢測并隔離變壓器內部故障。
• 接地保護：監測變壓器的接地故障，提供及時的故障響應和保護。

2. 高級監測與診斷

• 溫度監測：內置溫度傳感器監測變壓器的溫度，防止過熱對設備造成損害。
• 油位和氣體監測：監測變壓器油位和內部氣體，提供變壓器狀態的實時反饋。
• 絕緣監測：檢測變壓器的絕緣狀況，預警可能的絕緣失敗。

3. 通信和集成

• 支持多種通信協議：如Modbus、DNP3、IEC 61850等，方便與其他設備和系統進行集成。
• 網絡接口：提供網絡接口，支持?jǐn)?shù)據傳輸和遠程訪問，方便進行監控和管理。

4. 智能控制

• 自動重合閘：在發生暫時性故障時，自動嘗試恢復電力供應。
• 報警和通知：系統可以設置報警閾值，并在故障發生時發送通知，確保操作員能夠迅速響應。

5. 用戶友好界面

• 圖形化顯示：提供直觀的圖形用戶界面，便于配置和監控變壓器狀態。
• 遠程管理：支持遠程訪問和操作，允許從遠程地點進行系統管理和維護。

6. 可靠性和耐用性

• 堅固的設計：設備設計具有高耐用性，適應各種環境條件，確保長期穩定運行。
• 故障記錄：記錄歷史故障和事件數據，便于故障分析和維護。

MULTILIN 345-E-P5-G5-H變壓器保護系統 實物圖片：

english introduction:

MULTILIN 345-E-P5-G5-H is a part of the transformer protection system manufactured by GE (now GE Smart Grid), specifically designed for transformer protection and monitoring. This system includes multiple protection functions to ensure the safety and stability of the transformer under various operating conditions.

Main features and functions

Comprehensive transformer protection

Overcurrent protection: Provides protection against high currents to prevent transformer damage caused by overload or short circuit.

Differential protection: It achieves protection against internal faults in transformers by comparing input and output currents to detect and isolate internal faults in transformers.

Grounding protection: Monitor the grounding faults of transformers, provide timely fault response and protection.

Advanced Monitoring and Diagnosis

Temperature monitoring: The built-in temperature sensor monitors the temperature of the transformer to prevent overheating and damage to the equipment.

Oil level and gas monitoring: Monitor the oil level and internal gas of the transformer, providing real-time feedback on the status of the transformer.

Insulation monitoring: detecting the insulation condition of transformers and warning of possible insulation failures.

Communication and integration

Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., facilitating integration with other devices and systems.

Network interface: Provides a network interface that supports data transmission and remote access, facilitating monitoring and management.

intelligent control

Automatic reclosing: Automatically attempts to restore power supply in the event of a temporary fault.

Alarm and notification: The system can set alarm thresholds and send notifications when faults occur, ensuring that operators can respond quickly.

User friendly interface

Graphic display: Provides an intuitive graphical user interface for configuring and monitoring transformer status.

Remote management: supports remote access and operation, allowing system management and maintenance from a remote location.

Reliability and durability

Durable design: The equipment is designed to have high durability, adapt to various environmental conditions, and ensure long-term stable operation.

Fault record: Record historical fault and event data for easy fault analysis and maintenance.
