VMIVME5576是一款反射式存儲板，主要用于構建高速、確定性的數據傳輸網絡，尤其適用于實時性要求極高的應用場合。
VMIVME5576 反射式存儲板產品圖片展示
VMIVME5576 反射式存儲板產品視頻展示
VMIVME5576 反射式存儲板產品特點和注意事項
反射式內存板有幾個獨特的功能： 沒有建立通信所需的軟件 車載中斷生成能力。任何節點都可能在系統上的任何或所有其他節點上產生中斷。 便于在很長的鏈路長度（即高達2000米）上進行通信 可以選擇在特權或非特權模式下或同時在兩種模式下操作 內存可以配置為以A24或A32尋址模式運行 支持8位、16位、24位和32位傳輸（雙向） 注意力中斷被引導到七個可編程中斷級別之一 雙歐洲卡形狀系數 任何板都可以跳接為任何節點 可選擇256 K、512 K或1M字節的板載SRAM 512字節或4 KB FIFO的選項 | The Reflective Memory Board has several unique features: No software necessary to establish communications On-board interrupt generation ability. Any node may generateinterrupts on any or all other nodes on the system. Facilitates communications over very long link lengths, i.e., up to2,000 meters Can be selected to operate in privileged or nonprivileged modes or inboth modes at once Memory can be configured to run in either A24 or A32 addressingschemes Supports 8-, 16-, 24-, 32-bit transfers (bi-directional) Attention interrupts are channeled to one of seven programmableinterrupt levels Double Eurocard form factor Any board may be jumpered to be any Node Selectable 256 K, 512 K, or 1 Mbyte of SRAM on-board Options for 512 byte or 4 Kbyte FIFOs |
靜電防護：操作時采取靜電防護措施，避免靜電放電對板卡造成損害。
Notes:
Installation and connection: Ensure that the board is installed without power, correctly connect the fiber optic interface, pay attention to the insertion direction and cleanliness of the fiber optic to prevent signal attenuation.
Power and grounding: Confirm that the system power supply is stable, meets the power requirements of the board, and ensures good grounding to avoid interference and damage.
Heat dissipation and environment: Considering the potential heat generated by high-speed data transmission, it is necessary to ensure good ventilation of the chassis and avoid overheating. Meanwhile, pay attention to the working environment temperature and humidity, and maintain them within the specified range.
Network planning: Carefully plan the network topology structure before deployment, and choose the appropriate ring or star connection method according to application requirements.
Software configuration: Properly configure system software and drivers to ensure compatibility and optimal performance with VMIVME5576.
Data synchronization and verification: In high-speed transmission environments, pay attention to the synchronization mechanism and error verification of data to ensure data integrity and consistency.
Maintenance and monitoring: Regularly check the network status, including fiber optic connections, board status indicator lights, etc., to promptly identify and solve potential problems.
Electrostatic protection: Take electrostatic protection measures during operation to avoid damage to the board caused by electrostatic discharge.
